Запчасти Komatsu PC220LC-6LE FIG NO. A9-AA ГЕНЕРАТОР SI - VOLT, AMPERE ДВИГАТЕЛЬ - SADE-

|$0

1307 203 H1

ALTERNATOR - PRODUCTION ONLY

|$1

1310 137 H91

ALTERNATOR - SERVICE ONLY

1

1307 324 H1

FRAME, SLIP RING END

2

1236 651 H1

BEARING, SLIP RING END

3

1307 325 H1

ROTOR ASSEMBLY

4

1310 140 H1

STATOR ASSEMBLY

5

1307 327 H1

FRAME, DRIVE END

6

1213 268 H1

BEARING, DRIVE END

7

1310 141 H1

RECTIFIER BRIDGE ASSEMBLY

8

1307 329 H1

DIODE TRIO

9

1218 115 H1

REGULATOR

10

1307 330 H1

TERMINAL PACKAGE - OUTPUT

11

1307 331 H1

TERMINAL PACKAGE - RELAY

12

1307 332 H1

CONNECTOR REGULATOR STUD

13

1307 333 H1

CONNECTOR RELAY TERMINAL

14

1307 334 H1

CAPACITOR

15

1307 335 H1

BRUSH HOLDER ASSEMBLY

16

1307 336 H1

BRUSH AND ARM

17

1307 337 H1

RETAINER PLATE - DE

18

1218 242 H1

BUSHING HINGE - SRE

19

1218 130 H1

COVER - REGULATOR TERMINAL

N/I

1213 274 H1

CAP - RELAY TERMINAL

20

1307 338 H1

FAN

21

1310 142 H1

PULLEY

22

1218 126 H1

NUT -REGULATOR

23

120 622

NUT - RECTIFIER BRIDGE

24

1213 273 H1

NUT - SHAFT

25

1268 365 H1

SCREW AND LOCK WASHER - RECTIFIER BRIDGE

26

1236 654 H1

SCREW, BRUSH HOLDER - PIVOT

27

1268 365 H1

SCREW, REGULATOR - GROUND

28

1216 375 H1

SCREW, REGULATOR - INSULATOR

29

1307 339 H1

SCREW, CAPACITOR

30

1268 363 H1

SCREW, BEARING RETAINER PLATE

31

1307 340 H1

SCREW AND LOCK WASHER, GROUND - SLIP RING END

32

1268 370 H1

WASHER - SHAFT NUT

33

1307 341 H1

BOLT - THRU
