Запчасти Komatsu PC220LC-6LE FIG NO. K-A PPC ЛИНИЯ ХОДА заводской номер A879 И UP КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

08017-32807

CONDUIT

2

08034-00536

BAND, WHITE

3

20Y-62-27121

HOSE - 2950 MM

4

20Y-62-22790

BAND, RED

5

20Y-62-27131

HOSE - 3100 MM

6

20Y-62-22850

BAND, GREEN

7

20Y-62-27141

HOSE - 3300 MM

8

20Y-62-22820

BAND, BLUE

9

20Y-62-22872

HOSE - 1350 MM

10

20Y-62-22790

BAND, RED

11

203-62-52340

HOSE - 1000 MM

12

20Y-62-22820

BAND, BLUE

13

20Y-62-25990

HOSE - 2750 MM

14

20Y-62-22830

BAND, WHITE

15

08034-00519

BAND, WHITE

16

20Y-62-18910

BOLT, EYE

17

07000-02018

O-RING

18

20Y-62-18890

BOLT

19

07000-02015

O-RING

20

07235-10210

ELBOW

21

07002-01423

O-RING

22

20Y-62-27770

CLAMP

23

01010-81020

BOLT

24

01643-31032

WASHER

25

201-62-72570

CLAMP

26

01010-81016

BOLT

27

01643-31032

WASHER

28

08034-00536

BAND, WHITE

29

20Y-62-15831

BLOCK

30

01010-81045

BOLT

31

01643-31032

WASHER

32

07235-10311

ELBOW

33

07235-10210

ELBOW

34

07002-01423

O-RING

35

07230-20210

UNION

36

07002-01423

O-RING

37

20Y-62-15831

BLOCK

38

01010-81045

BOLT

39

01643-31032

WASHER

40

07235-10311

ELBOW

41

07235-10210

ELBOW

42

07002-01423

O-RING

43

07002-01423

O-RING
