Запчасти Komatsu PC220LC-6LE FIG NO. K-8A КАБИНА - РЫЧАГ С КЛАПАНОМ PPC ЭЛЕКТР. РЕГУЛЯТОР КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

207-06-61510

BASE, OPERATOR'S CAB - S/N A83001-A83986

1

20Y-06-25110

BASE, OPERATOR'S CAB - S/N A83987 AND UP

2

20Y-06-24121

SWITCH ASSEMBLY

3

01641-21223

WASHER

4

569-06-61960

RELAY - S/N A83001-A83986

5

01435-00610

BOLT - S/N A83001-A83986

6

20Y-06-27750

HARNESS ASSEMBLY - S/N A83001-A83986

6

20Y-06-27751

HARNESS ASSEMBLY - S/N A83987 AND UP

7

283-06-16110

BOX - S/N A83001-A83986

7

08044-11500

BOX - S/N A83987 AND UP

8

195-Z11-2290

COVER - S/N A83001-A83986

9

20Y-06-24130

SWITCH - S/N A83001 - A883986

10

283-06-16190

FUSE, 10 A - S/N A83001-A83986

10

08041-01000

FUSE, 10 A - S/N A83987 AND UP

11

205-06-73180

FUSE, 15 A - S/N A83001-A83986

11

08041-01500

FUSE, 15 A - S/N A83987 AND UP

12

22W-06-13160

FUSE, 20 A - S/N A83001-A83986

12

08041-02000

FUSE, 20 A - S/N A83987 AND UP

13

20Y-06-21460

CLIP - S/N A83001-A83986

14

20Y-06-23960

CLIP

15

01023-10625

SCREW

17

01435-01016

BOLT

18

20Y-979-2221

DUCT

19

01435-00610

BOLT

20

20Y-979-2231

DUCT

21

01435-00610

BOLT

22

20Y-979-2242

DUCT

23

01435-00610

BOLT

24

7861-94-4001

RESISTOR

25

01435-00820

BOLT

26

203-06-56230

BUZZER ASSEMBLY

27

01435-00610

BOLT

28

7834-21-7003

CONTROLLER

29

01435-00880

BOLT

30

20Y-06-24440

RELAY BOX - S/N A83001-A85000

30

20Y-06-25130

RELAY BOX - S/N A85001 AND UP

31

01435-00630

BOLT

32

20Y-06-24220

SHEET

33

08051-00801

CLIP

34

20Y-06-23521

LOCK

35

01435-00820

BOLT

36

08017-30701

CONDUIT

37

01010-81020

BOLT

38

01643-31032

WASHER
