Запчасти Komatsu PC220LC-6LE FIG NO. A-AA КОЛЕНВАЛ ДВИГАТЕЛЬ - SADE-

|$0

6736-31-1100

CRANKSHAFT ASSEMBLY

1

NSS

CRANKSHAFT

2

6732-31-1211

GEAR, CRANKSHAFT

3

6732-21-6150

PIN, DOWEL

|$4

6735-21-8100

SET, MAIN BEARING - STD

4

6735-21-8110

BEARING, MAIN UPPER

5

6742-01-4060

BEARING, THRUST

6

6735-21-8210

BEARING, LOWER

|$8

6736-29-8100

SET, MAIN BEARING - 0.01 IN. (0.25 MM) O/S

4

6735-29-8110

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$12

6736-28-8100

SET, MAIN BEARING - 0.02 IN. (0.50 MM) O/S

4

6735-28-8110

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

6735-82-8210

BEARING, LOWER

|$16

6736-27-8100

SET, MAIN BEARING - 0.03 IN. (0.75 MM) O/S

4

6735-27-8110

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$20

6736-26-8100

SET, MAIN BEARING - 0.04 IN. (1.00 MM) O/S

4

6735-26-8110

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$24

6731-21-8610

SET, CRANKSHAFT THRUST BEARING - 0.02 IN. (0.50 MM) O/S

5

NSS

BEARING, THRUST

6

6735-28-8210

BEARING, LOWER

|$28

6731-21-8620

SET, CRANKSHAFT THRUST BEARING - 0.04 IN. (1.00 MM) O/S

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

7

6736-39-1221

KIT, FRONT CRANKSHAFT SLEEVE

8

6736-39-1140

KIT, REAR CRANKSHAFT SLEEVE
