Запчасти Komatsu PC220LC-6LE FIG NO. K-A СИДЕНЬЕ ОПЕРАТОРА ASSEMBLY - заводской номер A8 И UP КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

20Y-57-A1610

SEAT ASSEMBLY, OPERATOR'S

1

206-57-A1630

UPPER SEAT ASSEMBLY

2

206-57-A1640

BACK COVER KIT

3

206-57-A1430

BACK FOAM KIT

4

206-57-A1650

SEAT COVER KIT

5

206-57-A1450

SEAT FOAM KIT

6

206-57-A1460

FRAME KIT

7

206-57-A1470

CABLE ADJUSTMENT KIT

8

206-57-A1480

HEIGHT RISER SPRING KIT

9

206-57-A1490

HEIGHT RISER LATCH KIT

10

206-57-A1510

DAMPER ASSEMBLY KIT

11

206-57-A1520

SUSPENSION ASSEMBLY

12

206-57-A1660

FORWARD AND BACKWARD ADJUSTMENT KIT

13

206-57-A1540

WEIGHT ADJUSTMENT KIT

14

206-57-A1550

UP STOP / BUMP STOP KIT

15

206-57-A1560

HANDLE KIT, YELLOW

16

206-57-A1570

HEIGHT RISER KIT

17

206-57-A1580

SUSPENSION COVER KIT

18

206-57-A1590

SLIDE RAIL HANDLE

19

206-57-A1610

BEARING KIT

20

206-57-A1670

HEADREST KIT

21

206-57-A1680

ARMREST ASSEMBLY - RIGHT HAND

22

206-57-A1690

ARMREST ASSEMBLY - LEFT HAND
