Запчасти Komatsu PC220LC-6LC FIG NO. T- ЦИЛИНДР КОВША ДЛЯ .M, .M, И .M РУКОЯТИ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

206-63-02130

CYLINDER ASSEMBLY, BUCKET

1

206-63-73340

CYLINDER

2

707-76-80010

BUSHING

3

07145-00080

SEAL, DUST

4

206-63-73320

ROD, PISTON

5

707-76-80020

BUSHING

6

205-70-62140

SEAL, DUST

7

707-27-13620

HEAD, CYLINDER

8

07179-13104

RING, SNAP

9

195-63-94170

SEAL

10

707-52-90650

BUSHING

11

707-51-90030

PACKING, ROD

12

07000-15125

O-RING

13

07001-05125

RING, BACK-UP

14

707-51-90630

RING, BUFFER

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-13411

PISTON

18

707-44-13180

RING, PISTON

19

707-39-13110

RING, WEAR

20

707-44-13911

RING

21

07165-16870

NUT

22

07020-00000

FITTING, GREASE

23

07020-00900

FITTING, GREASE

24

206-63-73370

TUBE

25

07372-21060

BOLT

26

07372-21045

BOLT

27

01643-51032

WASHER

28

07000-13030

O-RING

29

707-88-95980

BAND

30

707-88-96100

BAND

31

01010-51035

BOLT

32

01643-51032

WASHER

33

07282-02793

CLAMP

34

01010-51020

BOLT

35

01643-31032

WASHER

|$39

707-98-47620

SERVICE KIT, BUCKET CYLINDER

3

07145-00080

SEAL, DUST

6

205-70-62140

SEAL, DUST

9

195-63-94170

SEAL, DUST

11

707-51-90030

PACKING, ROD

12

07000-15125

O-RING

13

07001-05125

RING, BACK-UP

14

707-51-90630

RING, BUFFER

18

707-44-13180

RING, PISTON

19

707-39-13110

RING, WEAR

28

07000-13030

O-RING
