Запчасти Komatsu PC220LC-6LC FIG NO. T- ЦИЛИНДР РУКОЯТИ РАБОЧЕЕ ОБОРУДОВАНИЕ
№
Артикул
Название
Примечание
Количество
|$0
206-63-02521
CYLINDER ASSEMBLY, ARM
1
206-63-63340
CYLINDER
2
707-76-80010
BUSHING
3
07145-00080
SEAL, DUST
4
206-63-63320
ROD, PISTON
5
707-27-14620
HEAD, CYLINDER
6
07179-13114
RING, SNAP
7
176-63-56170
SEAL, DUST
8
707-52-90750
BUSHING
9
707-51-10030
PACKING, ROD
10
07000-15135
O-RING
11
07001-05135
RING, BACK-UP
12
707-51-10630
RING, BUFFER
13
01010-81875
BOLT
14
707-41-11840
WASHER
15
707-36-14360
PISTON
16
707-44-14180
RING, PISTON
17
707-39-14820
RING, WEAR
18
707-44-14910
RING
19
07165-16870
NUT
20
707-71-61011
PLUNGER
21
707-71-60230
PLUNGER
22
07020-00900
FITTING
23
707-71-32740
COLLAR
24
07001-05135
RING, BACK-UP
25
07000-15135
O-RING
26
04260-00635
BALL
27
707-71-91270
CAP
28
206-63-63370
TUBE
29
20D-62-17860
ELBOW
30
07372-21060
BOLT
31
07372-21045
BOLT
32
01643-51032
WASHER
33
07000-13030
O-RING
34
01010-51080
BOLT
35
01643-31032
WASHER
36
07000-13035
O-RING
37
707-88-95401
BRACKET
38
707-88-95380
BAND
39
01010-51035
BOLT
40
01643-51032
WASHER
41
707-88-11560
PLATE
42
07283-22738
CLIP
43
01599-01011
NUT
44
01643-31032
WASHER
|$48
707-99-58200
SERVICE KIT, ARM CYLINDER
3
07145-00080
SEAL, DUST
7
176-63-56170
SEAL, DUST
9
707-51-10030
PACKING, ROD
10
07000-15135
O-RING
11
07001-05135
RING, BACK-UP
12
707-51-10630
RING, BUFFER
16
707-44-14180
RING, PISTON
17
707-39-14820
RING, WEAR
33
07000-13030
O-RING
36
07000-13035
O-RING
Выбрано товаров: 56
