Запчасти Komatsu PC220LC-6LC ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

3737-11-1010

HEAD, CYLINDER

1

NSS

HEAD, CYLINDER

2

1295 538 H2

PLUG, EXPANSION

3

6732-11-1930

PLUG, PIPE (1/8 NPT)

4

6732-11-1910

PLUG, PIPE (1/2 NPT)

|$5

1240 104 H92

VALVE, INTAKE

5

1240 127 H1

COLLET, VALVE

10

NSS

VALVE, INTAKE

|$8

1240 105 H92

VALVE EXHAUST

5

1240 127 H1

COLLET, VALVE

11

NSS

VALVE, EXHAUST

6

1304 604 H1

SPRING, VALVE

7

1240 132 H1

RETAINER, VALVE SPRING

8

1240 164 H1

SEAL, VALVE STEM

9

1304 603 H1

SEAL, VALVE STEM

12

6732-11-1920

PLUG, PIPE (3/4 NPT)

13

1294 507 H2

BOLT (M12x1.75x70)

14

1294 508 H2

BOLT (M12x1.75x120)

15

6736-11-6110

TUBE, AFTERCOOLER

16

6735-11-1811

GASKET, CYLINDER HEAD (STD)

|$20

1294 396 H2

GASKET, CYLINDER HEAD (.25MM OVERSIZE)

|$21

1240 728 H3

GASKET, CYLINDER HEAD (.50MM OVERSIZE)

17

1240 668 H1

INSERT, VALVE EXHAUST

18

1240 779 H1

INSERT, VALVE INTAKE

19

1240 677 H1

GUIDE, VALVE STEM

20

1240 678 H1

GUIDE, VALVE STEM

21

1240 763 H1

GUIDE, VALVE STEM
