Запчасти Komatsu PC220LC-6LC FIG NO. P- КОНЕЧНАЯ ПЕРЕДАЧА НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

20Y-27-00200

FINAL DRIVE ASSEMBLY

|$2

150-27-00029

FLOATING SEAL ASSEMBLY

2

150-27-00263

SEAL RING ASSEMBLY

3

144-873-0310

O-RING ASSEMBLY

4

20Y-27-22180

HUB

5

20Y-27-22230

BEARING

6

20Y-27-22280

O-RING

7

20Y-27-22260

LOCK

8

20Y-27-22270

LOCK

9

01010-81020

BOLT

10

20Y-27-22170

CARRIER

11

20Y-27-22140

GEAR

12

20Y-27-22220

BEARING

13

20Y-27-21250

WASHER

14

20Y-27-21230

PIN

15

20Y-27-21290

PIN

16

20Y-27-13310

WASHER

17

20Y-27-22130

GEAR

18

20Y-27-22240

WASHER

19

20Y-27-22150

GEAR

20

20Y-27-22160

CARRIER

21

20Y-27-22120

GEAR

22

20Y-27-22210

BEARING

23

20Y-27-21240

WASHER

24

20Y-27-21220

PIN

25

20Y-27-21280

PIN

26

20Y-27-22110

SHAFT

27

20Y-27-21310

WASHER

28

20Y-27-22250

BUTTON

29

20Y-27-22190

COVER

30

20Y-27-13281

BOLT

31

01643-31645

WASHER

32

07049-01012

PLUG

33

07044-12412

PLUG

34

07002-02434

O-RING

35

20Y-27-11581

SPROCKET

36

20Y-27-11561

BOLT

37

01010-81670

BOLT, MOUNT TRAVEL MOTOR TO FRAME

38

01643-31645

WASHER

39

20Y-30-21180

COVER

40

01010-51230

BOLT

41

01643-31232

WASHER
