Запчасти Komatsu PC220LC-6LC FIG NO. K-A КАБИНА (ПЕРЕДН. ОКНА) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

20Y-54-36702

FRONT WINDOW ASSEMBLY

1

20Y-54-36712

WINDOW

2

20Y-54-38122

GLASS

3

20Y-54-38132

WEATHER STRIP

4

20Y-54-38142

SEAL

5

20Y-54-38152

SEAL

6

20T-54-75270

LATCH ASSEMBLY, LH

7

20T-54-75280

LATCH ASSEMBLY, RH

8

01435-30816

BOLT

9

20Y-54-14290

STOPPER

10

01580-11008

NUT

11

20Y-54-14590

HANDLE

12

01023-10616

SCREW

13

20Y-54-14310

STRIKER

14

20Y-54-14280

SCREW

15

20Y-54-36833

BLOCK, LH

16

20Y-54-36843

BLOCK, RH

17

01252-50635

BOLT

18

01641-50608

WASHER

19

20Y-54-39151

ROLLER

20

205-54-63310

LOCK ASSEMBLY

21

01435-30820

BOLT

22

20Y-54-39363

BRACKET

23

01435-30820

BOLT

24

154-61-16570

WASHER

25

08074-40000

SWITCH

26

01583-11811

NUT

27

20Y-54-39590

WIRING HARNESS

28

20Y-54-36150

GROMMET

29

08051-00801

CLIP

30

20Y-54-14721

LOCK

31

01435-30820

BOLT

|$32

20Y-54-36103

LOWER WINDOW ASSEMBLY

32

20Y-54-36122

LATCH ASSEMBLY, LH

33

20Y-54-36132

LATCH ASSEMBLY, RH

34

20Y-54-36142

PLATE

35

20Y-54-36191

GROMMET

36

01225-70612

SCREW

37

20Y-54-36211

COVER

38

20Y-54-36113

GLASS

39

20Y-54-36171

SEAT

40

01370-00620

SCREW

41

20Y-54-36182

STOPPER

42

01435-30820

BOLT

43

20Y-54-36230

SHIM
