ТУРБОНАГНЕТАТЕЛЬ

Запчасти Komatsu PC220LC-6LC ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC220LC-6LC - ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ
12
6
13
10
2
11
3
5
9
8
27
28
23
14
1
4
22
17
16
31
15
14
18
32
21
7
13
20
29
19
30
25
26
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

1295 324 H91

TURBOCHARGER ASSEMBLY

1

1240 503 H1

HOUSING, COMPRESSOR

2

1240 504 H1

DIFFUSER, TURBOCHARGER

3

1240 489 H1

SEAL, RECTANGULAR RING

|$4

1240 505 H91

ROTOR ASSEMBLY

4

6736-81-8250

NUT, LOCK

5

1240 493 H1

SLINGER, OIL

6

1240 494 H1

COLLAR, THRUST

7

1240 500 H2

IMPELLER, TUR COMPRESSOR

8

1278 293 H1

SHAFT & WHEEL

9

6736-81-8320

SEAL, SPLIT RING

10

1246 467 H1

BAFFLE, OIL

11

1246 465 H1

BOLT, FLAT HEAD CAP (M5x0.80x16)

12

1270 365 H1

BEARING, TUR THRUST

13

6736-81-8360

RING, RETAINING

14

6736-81-8370

BEARING, TURBOCHARGER

15

6736-81-8380

BOLT, HEXAGON HEAD SET (M8x1.25x12)

16

1240 486 H1

LOCKPLATE

N/I

1246 470 H1

WASHER, LOCK

17

1240 487 H1

PLATE, CLAMPING

18

1278 296 H1

BOLT, HEXAGON HEAD SET

19

1295 508 H1

HOUSING, TUR BEARING

20

6736-81-8430

SHIELD, TURBOCHARGER HEAT

21

6736-81-8440

SEAL, SPLIT RING

22

1240 497 H1

HOUSING, TURBINE

23

1240 506 H1

O-RING

25

1246 472 H2

DATAPLATE

26

6736-81-8480

SCREW, DRIVE

27

1240 501 H1

CLAMP, V BAND

28

1240 491 H1

NUT, REGULAR HEXAGON

29

1240 576 H1

GASKET, TURBOCHARGER

30

1304 931 H1

GASKET, OIL DRAIN

31

6736-51-8140

CONNECTOR, FEMALE

32

6736-51-8710

O-RING
