Запчасти Komatsu PC220LC-6L FIG NO. C- СИСТЕМА ОХЛАЖДЕНИЯ СИСТЕМА ОХЛАЖДЕНИЯ

1

20Y-03-21111

RADIATOR

2

205-03-71280

CAP, RADIATOR

3

205-03-62660

PLUG

4

07000-01007

O-RING

5

203-03-41411

HOSE

6

20Y-03-11330

CLIP

7

01010-51025

BOLT

8

01643-31032

WASHER

9

20Y-03-21340

SEAL

10

20Y-03-21350

SEAL

11

NS

BRACKET

12

NS

BRACKET

13

20Y-03-21320

SEAL

14

20Y-03-21410

STAY

15

20Y-03-21420

STAY

16

01010-61230

BOLT

17

01643-31232

WASHER

18

20Y-03-21121

COOLER, OIL

19

20Y-03-21330

SEAL

20

01010-51225

BOLT

21

01643-31232

WASHER

22

20Y-03-21430

SEAL

23

20Y-03-21141

NET

24

01434-10616

BOLT

25

01643-30823

WASHER

26

20Y-03-21430

SEAL

27

20Y-03-21132

SHROUD, FAN

28

01580-01008

NUT

29

01435-20816

BOLT

30

20Y-03-14110

SEAL

31

20Y-03-21380

PLATE

32

01010-51025

BOLT

33

01643-31032

WASHER

34

206-03-61111

BRACKET

35

01010-51025

BOLT

36

01643-31032

WASHER

37

6209-61-4100

AFTER COOLER

38

01010-51045

BOLT

39

01643-31032

WASHER

40

6110-23-6490

SPACER

41

206-03-61121

BRACKET

42

01010-51025

BOLT

43

01643-31032

WASHER

44

20Y-03-21260

SEAL

45

206-03-61130

SEAL

46

206-03-61140

SEAL
