Запчасти Komatsu PC220LC-6 ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC220LC-6 - ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
1
1
1
1
2
3
4
5
6
6
7
8
8
9
10
11
12
13
14
15
16
16
17
18
19
20
21
22
23
23
24
25
25
26
27
28
29
30
30
31
32
32
33
34
35
36
37
37
38
39
39
40
41
42
43
44
45
46
46
47
48
49
50
51
52
52
53
54
54
55

Артикул

Название

Примечание

Количество

|$6

723-49-13702

VALVE ASS'Y

|$7

723-49-13701

VALVE ASS'Y

|$8

723-49-13700

VALVE ASS'Y

|$9

723-49-13104

VALVE ASS'Y

|$10

723-49-13103

VALVE ASS'Y

|$11

723-49-13102

VALVE ASS'Y

|$13

BODY SUB ASS'Y

|$14

BODY SUB ASS'Y

|$15

BODY SUB ASS'Y

|$16

BODY SUB ASS'Y

|$17

BODY SUB ASS'Y

|$18

B0DY SUB ASS'Y

1

723-46-41110

VALVE

2

723-46-41120

VALVE

|$21

723-46-40100

VALVE ASS'Y

3

SLEEVE

4

PISTON SUB ASS'Y

5

SPRING

6

SEAL

7

700-93-11320

O-RING

8

723-46-41950

RING

9

07002-13634

O-RING

|$29

723-46-40702

VALVE ASS'Y

10

SLEEVE

11

PISTON

12

SPRING

13

SEAL

14

SEAL

15

700-93-11320

O-RING

16

723-46-41950

RING

17

07002-13634

O-RING

18

723-46-42981

PLUG

19

07002-12434

O-RING

|$40

723-46-41100

VALVE ASS'Y

20

SLEEVE

21

PISTON SUB ASS'Y

22

SPRING

23

SEAL

24

700-93-11320

O-RING

25

723-46-41950

RING

26

07002-13634

O-RING

|$48

723-46-45100

VALVE ASS'Y

|$49

723-46-45100

VALVE ASS'Y

27

SLEEVE

28

PISTON SUB ASS'Y

29

SPRING

30

SEAL

31

700-93-11320

O-RING

32

723-46-41950

RING

33

07002-13634

O-RING

|$57

723-46-46101

VALVE ASS'Y

34

SLEEVE

35

PISTON SUB ASS'Y

36

SPRING

37

SEAL

38

700-93-11320

O-RING

39

723-46-41950

RING

40

07002-13634

O-RING

|$65

723-46-43200

VALVE ASS'Y

41

SLEEVE

42

VALVE SUB ASS'Y

43

SPRING

44

SEAL

45

700-93-11320

O-RING

46

723-46-41950

RING

47

07002-13634

O-RING

48

723-46-41980

RETAINER

|$74

723-46-46300

VALVE ASS'Y

49

SLEEVE

50

PISTON SUB ASS'Y

51

SPRING

52

SEAL

53

700-93-11320

O-RING

54

723-46-41950

RING

55

07002-13634

O-RING

Выбрано товаров: 75
