Запчасти Komatsu PC220LC-5 КОНЕЧНАЯ ПЕРЕДАЧА И ЗВЕЗДОЧКА ХОД И НИЖН.CARRIAGE

|$0

206-27-00034

DRIVE ASSEMBLY, FINAL

1

20Y-27-13130

SHAFT, FINAL DRIVE

|$2

150-27-00028

SEAL ASSEMBLY, FLOATING

2

150-27-00262

RING ASSEMBLY, SEAL

|$4

150-27-24132

RING

3

144-873-0310

O-RING ASSEMBLY

|$6

144-873-3430

RING

4

20Y-27-11570

BEARING

5

20Y-27-13120

HUB

5A

20Y-27-13290

O-RING

6

07044-12412

PLUG

7

07002-02434

O-RING

8

20Y-27-11581

SPROCKET

9

20Y-27-11560

BOLT

10

20Y-27-00031

KIT, SPACER

|$15

20Y-27-11390

SPACER 4.7 mm

|$16

20Y-27-11370

SPACER 4.75 mm

|$17

20Y-27-11380

SPACER 4.8 mm

|$18

20Y-27-11310

SPACER 4.85 mm

|$19

20Y-27-11320

SPACER 4.9

|$20

20Y-27-11330

SPACER 4.95 mm

|$21

20Y-27-11340

SPACER 5.0 mm

|$22

20Y-27-11350

SPACER 5.05 mm

|$23

20Y-27-11360

SPACER 5.10 mm

11

20Y-27-13270

RETAINER

12

20Y-27-11180

BOLT

13

01010-51645

BOLT

14

01643-31645

WASHER

15

20Y-27-13190

GEAR

16

20Y-27-13230

CARRIER

17

20Y-27-13310

WASHER, THRUST

18

20Y-27-13210

GEAR

19

20Y-27-13220

GEAR

20

20Y-27-13260

BEARING

21

20Y-27-13240

PIN

22

20Y-27-11240

HOLDER

23

01011-51200

BOLT

24

20Y-27-13150

CARRIER

25

20Y-27-11250

SPACER

26

20Y-27-13140

GEAR

27

20Y-27-13180

BEARING

28

20Y-27-13160

PIN

29

20Y-27-13170

HOLDER

30

01010-51055

BOLT

31

04260-01905

BALL

32

20Y-27-13110

COVER

33

07044-12412

PLUG

34

07002-02434

O-RING

35

20Y-27-13281

BOLT

36

01643-31645

WASHER

37

07049-01215

PLUG

38

01010-51670

BOLT

39

01643-31645

WASHER
