Запчасти Komatsu PC220LC-5 МЕХАНИЗМ ПОВОРОТА МЕХ-М ОТБОРА МОЩНОСТИ И ПОВОРОТН.

|$0

20Y-26-00010

MACHINERY ASSEMBLY, SWING

1

20Y-26-14110

COVER, SWING MACHINERY

2

20Y-26-14120

BASE, SWING MACHINERY

3

01010-51690

BOLT

4

01643-31645

WASHER

5

01011-51620

BOLT

6

01643-31645

WASHER

7

20Y-26-14280

GEAR

8

20Y-26-14270

GEAR

9

06002-30218

BEARING

10

07000-05175

O-RING

11

20Y-26-00040

SHIM KIT

12

20Y-26-14190

CAGE

13

01010-51030

BOLT

14

01643-31032

WASHER

15

07042-30108

PLUG

16

20Y-26-14260

GEAR

17

06002-30310

BEARING

18

07000-05125

O-RING

19

20Y-26-00030

SHIM KIT

20

20Y-26-14130

CAGE

21

04020-01228

PIN, DOWEL

22

01010-51030

BOLT

23

01643-31032

WASHER

24

20Y-26-13130

GEAR

25

205-32-51210

BOLT

26

20Y-26-13320

PLATE

27

20Y-26-12271

CARRIER

28

20Y-26-13221

GEAR

29

20Y-26-13231

BEARING

30

20Y-26-13241

PIN

31

20Y-26-12291

HOLDER

32

01011-51200

BOLT

33

06000-22218

BEARING

34

20Y-26-13280

SPACER

35

20Y-26-12541

CASE, SWING MACHINERY

36

01011-51620

BOLT

37

01643-31645

WASHER

38

06000-22319

BEARING

39

20Y-26-13291

COVER

40

01010-51045

BOLT

41

01643-31032

WASHER

42

07012-00125

SEAL

43

20Y-26-13271

SHAFT
