Запчасти Komatsu PC220LC-5 ВОДЯНАЯ ПОМПА СИСТЕМА ОХЛАЖДЕНИЯ

Схема запчастей Komatsu PC220LC-5 - ВОДЯНАЯ ПОМПА СИСТЕМА ОХЛАЖДЕНИЯ
20
19
9
8
17
10
18
13
24
14
1
6
23
12
7
4
5
11
2
3
16
15
21
22

Артикул

Название

Примечание

Количество

|$0

6206-61-1103

WATER PUMP ASSEMBLY

|$1

6206-61-1102

WATER PUMP ASSEMBLY

1

NSS

BODY

2

6206-61-1341

SHAFT

|$4

6206-61-1340

SHAFT

3

6206-61-1410

BOSS

4

6221-61-1520

SEAL, WATER

5

6206-61-1553

IMPELLER

6

6206-61-1120

COVER

7

6206-61-1130

GASKET

8

01236-40816

SCREW

9

203-977-4130

VALVE

|$12

6206-61-8620

TEE (WITH CORROSION RESISTOR TYPE)

10

07042-00312

PLUG

|$14

6136-55-7610

NIPPLE (WITH CORROSION RESISTOR TYPE)

11

7861-92-3320

SENSOR, ENGINE WATER TEMPERATURE

12

08036-10814

CLIP

13

07000-03040

O-RING

14

6206-61-1710

GASKET

15

01435-20855

BOLT

16

01435-20855

BOLT

|$21

01435-20875

BOLT (WITH ALTERNATOR TYPE COVER)

17

600-421-6110

THERMOSTAT

18

6140-11-6331

GASKET

19

6204-11-6430

CONNECTOR

20

01435-20820

BOLT

21

6207-61-3240

PULLEY, NON HARDENING

22

01435-20820

BOLT

23

04120-21750

V-BELT

|$29

04120-21749

V-BELT

|$30

04120-21750

V-BELT

|$31

04120-21750

V-BELT (FOR LARGE PULLEY)

|$32

04120-21749

V-BELT (FOR BRUSHLESS ALTERNATOR)

Выбрано товаров: 33
