Запчасти Komatsu PC220LC-5 ТОПЛ. НАСОС РЕГУЛЯТОР (INTERNAL ASSEMBLY) USED ON ДВИГАТЕЛИ С SERIAL NUMBERS 7 И UP ТОПЛИВН. СИСТЕМА

|$1

DK105400-5532

GOVERNOR ASSEMBLY

1

DK154000-6300

HOUSING

2

DK029632-5070

O-RING

3

DK154007-2900

PLUG

4

DK154007-0200

ADAPTER

5

DK020018-1840

BOLT

6

DK154350-1900

PLATE

7

DK020006-1440

BOLT

8

DK154010-0100

SCREW

9

DK154011-0100

NUT, LOCK

10

DK154050-1720

LIMITER

11

DK154101-0120

FLYWEIGHT ASSEMBLY

12

DK029321-2020

WASHER, SPRING

13

DK029321-2030

NUT

14

DK154123-0120

SLEEVE

15

DK029311-0010

SHIM, (0.2 MM)

|$17

DK029311-0180

SHIM, (0.3 MM)

|$18

DK029311-0190

SHIM (0.40 MM)

|$19

DK139410-0000

SHIM, (0.5 MM)

|$20

DK029311-0210

SHIM, (1.0 MM)

|$21

DK139410-0100

SHIM, (1.5 MM)

|$22

DK139410-3000

SHIM, (2.0 MM)

|$23

DK139410-3100

SHIM, (3.0 MM)

|$24

DK139410-3200

SHIM, (4.0 MM)

16

DK154154-0701

SPRING

17

DK154177-0620

CAPSULE, SPRING

18

DK029201-6010

NUT

19

DK154210-0920

GUIDE, LEVER ASSEMBLY

20

DK154230-3920

LINK

21

DK016010-0540

RING, SNAP

22

DK154236-4100

LEVER, TENSION

23

DK154350-7700

GASKET
