Запчасти Komatsu PC220LC-5 ТОПЛИВН. ФОРСУНКА И СЛИВНАЯ ТРУБКА ТОПЛИВН. СИСТЕМА

|$0

6209-11-3100

NOZZLE HOLDER ASSEMBLY

|$1

6207-11-3100

NOZZLE HOLDER ASSEMBLY

1

6202-13-3110

HOLDER ASSEMBLY

1

6207-11-3110

HOLDER ASSEMBLY

2

DK150508-5900

PIN

3

DK150560-0400

SEAT

3

DK150515-9900

SEAT

4

DK150562-4300

SPRING

5

DK150531-0000

SHIM, (0.50 MM)

|$9

DK150531-0100

SHIM, (0.525 MM)

|$10

DK150531-0200

SHIM, (0.55 MM)

|$11

DK150531-0300

SHIM, (0.575 MM)

|$12

DK150531-0400

SHIM, (0.60 MM)

|$13

DK150531-0500

SHIM, (0.625 MM)

|$14

DK150531-0600

SHIM, (0.65 MM)

|$15

DK150531-0700

SHIM, (0.675 MM)

|$16

DK150531-0800

SHIM, (0.70 MM)

|$17

DK150531-0900

SHIM, (0.725 MM)

|$18

DK150531-1000

SHIM, (0.75 MM)

|$19

DK150531-1100

SHIM, (0.775 MM)

|$20

DK150531-1200

SHIM, (0.80 MM)

|$21

DK150531-1300

SHIM, (0.825 MM)

|$22

DK150531-1400

SHIM, (0.85 MM)

|$23

DK150531-1500

SHIM, (0.875 MM)

|$24

DK150531-1600

SHIM, (0.90 MM)

|$25

DK150531-1700

SHIM, (0.925 MM)

|$26

DK150531-1800

SHIM, (0.95 MM)

|$27

DK150531-1900

SHIM, (0.975 MM)

|$28

DK150531-2000

SHIM, (1.0 MM)

|$29

DK150531-2100

SHIM, (1.025 MM)

|$30

DK150531-2200

SHIM, (1.05 MM)

|$31

DK150531-2300

SHIM, (1.075 MM)

|$32

DK150531-2400

SHIM, (1.10 MM)

|$33

DK150531-2500

SHIM, (1.125 MM)

|$34

DK150531-2600

SHIM, (1.15 MM)

|$35

DK150531-2700

SHIM, (1.175 MM)

|$36

DK150531-2800

SHIM, (1.200 MM)

|$37

DK150531-2900

SHIM, (1.225 MM)

|$38

DK150531-3000

SHIM, (1.25 MM)

|$39

DK150531-3100

SHIM, (1.275 MM)

|$40

DK150531-3200

SHIM, (1.30 MM)

|$41

DK150531-3300

SHIM, (1.325 MM)

|$42

DK150531-3400

SHIM, (1.35 MM)

|$43

DK150531-3500

SHIM, (1.375 MM)

|$44

DK150531-3600

SHIM, (1.40 MM)

|$45

DK150531-3700

SHIM, (1.425 MM)

|$46

DK150531-3800

SHIM, (1.45 MM)

|$47

DK150531-3900

SHIM, (1.475 MM)

|$48

DK150531-4000

SHIM, (1.50 MM)

|$49

DK150534-3600

SHIM, (0.10 MM)

|$50

DK150534-3700

SHIM, (0.20 MM)

|$51

DK150534-3800

SHIM, (0.30 MM)

|$52

DK150534-3900

SHIM, (0.40 MM)

|$53

DK150534-4000

SHIM, (0.50 MM)

|$54

DK150534-4100

SHIM, (0.52 MM)

|$55

DK150534-4200

SHIM, (0.54 MM)

|$56

DK150534-4300

SHIM, (0.56 MM)

|$57

DK150534-4400

SHIM, (0.58 MM)

6

DK150524-4600

SPACER

7

DK150655-0000

NUT, RETAINING

8

6209-11-3130

NOZZLE

8

6207-11-3130

NOZZLE

9

6204-11-3880

GASKET

10

6204-11-3850

SEAL, DUST

11

6204-11-3810

HOLDER

12

01435-01035

BOLT

13

6204-11-3830

WASHER

14

6204-71-9100

HOSE, SPILL

15

6204-71-5581

CAP

16

6204-71-9500

HOSE, SPILL

17

07285-00100

CLIP

|$71

07285-00080

CLIP

18

07285-00100

CLIP

|$73

07285-00080

CLIP

19

07285-00100

CLIP

20

08036-11214

CLIP

|$76

08036-10814

CLIP
