Запчасти Komatsu PC220LC-5 ПОРШЕНЬ И ШАТУН БЛОК ЦИЛИНДРОВ

1

6209-31-2141

PISTON (S) (STANDARD)

|$1

6209-39-2141

PISTON (S) (OVERSIZE 0.25 MM)

|$2

6209-38-2141

PISTON (S) (OVERSIZE 0.50 MM)

2

6207-31-2420

PIN, PISTON

3

04065-03012

RING, SNAP

|$5

6207-31-2500

PISTON RING ASSY PER CYLINDER (STANDARD)

4

NSS

RING, TOP

5

NSS

RING, SECOND

6

NSS

RING, OIL

|$9

6207-39-2500

PISTON RING ASSY PER CYLINDER (OVERSIZE .25 MM)

4

NSS

RING, TOP

5

NSS

RING, SECOND

6

NSS

RING, OIL

|$13

6207-38-2500

PISTON RING ASSY PER CYLINDER (OVERSIZE .50 MM)

4

NSS

RING, TOP

5

NSS

RING, SECOND

6

NSS

RING, OIL

|$17

6207-31-3100

ROD ASSEMBLY, CONNECTING

7

NSS

ROD, CONNECTING

8

NSS

CAP

9

6207-31-3130

BUSHING

10

6204-31-3310

BOLT

|$22

6207-31-3300

PIN ASSEMBLY, CRANK BEARING (STANDARD)

11

NSS

BEARING, UPPER

12

NSS

BEARING, LOWER

|$25

6207-39-3300

PIN ASSEMBLY, CRANK BEARING (UNDERSIZE 0.25 MM)

11

NSS

BEARING, UPPER

12

NSS

BEARING, LOWER

|$28

6207-38-3300

PIN ASSEMBLY, CRANK BEARING (UNDERSIZE 0.50 MM)

11

NSS

BEARING, UPPER

12

NSS

BEARING, LOWER
