Запчасти Komatsu PC220LC-5 ГОЛОВКА ЦИЛИНДРОВ ГОЛОВКА ЦИЛИНДРОВ

|$0

6209-11-1100

CYLINDER HEAD ASSEMBLY, WITHOUT VALVE

1

NSS

HEAD, CYLINDER

2

6204-19-1310

GUIDE, VALVE

3

6209-11-1430

SEAT, INTAKE VALVE (STANDARD)

|$4

6209-19-1430

SEAT, INTAKE VALVE (OVER SIZE, 0.25 MM)

|$5

6209-18-1430

SEAT, INTAKE VALVE (OVER SIZE, 0.50 MM)

4

6207-11-1440

SEAT, EXHAUST VALVE (STANDARD)

|$7

6207-19-1440

SEAT, EXHAUST VALVE (OVER SIZE, 0.25 MM)

|$8

6207-18-1440

SEAT, EXHAUST VALVE (OVER SIZE, 0.50 MM)

5

07046-41008

PLUG

6

07046-41810

PLUG

7

07046-42216

PLUG

8

07046-42516

PLUG

9

02720-40104

PLUG

10

6209-41-4110

VALVE, INTAKE

11

6209-41-4210

VALVE, EXHAUST

12

6204-41-4510

SEAT, SPRING

13

6204-41-4520

COLLET

14

6204-41-4550

CAP, VALVE

15

6204-41-4431

SPRING, VALVE

16

6204-41-4540

SEAL, VALVE

17

6206-11-1930

HANGER, FRONT

|$22

6207-11-1910

HANGER, FRONT (WITH ALTERNATOR COVER)

|$23

6207-61-8110

HANGER, FRONT (WITH CORROSION RESISTOR)

18

6206-11-1910

HANGER, REAR

19

01435-01020

BOLT

20

6206-11-1830

GASKET, HEAD

21

6204-13-1610

BOLT, HEAD

22

01643-51232

WASHER
