Запчасти Komatsu PC220LC-5 МАРКИРОВКА заводской номер A78 И UP - ШАССИ - АНГЛ. МАРКИРОВКА

1

154-54-23260

PAD, ANTI-SKID

2

09669-00002

PLATE, CAUTION - FUEL TANK

3

09650-30104

PLATE, INSTRUCTION - COOLANT OVERFLOW

4

09668-03000

PLATE, SAFETY - RADIATOR CAP REMOVAL

5

20Y-54-12730

PAD, ANTI-SKID

6

09667-03000

PLATE, SAFETY - KEEP HANDS CLEAR OF ENGINE FAN

7

09669-00003

PLATE, CAUTION - HYDRAULIC OIL TANK

8

09653-03000

PLATE, SAFETY - HYDRAULIC TANK CAP REMOVAL

9

20Y-00-11390

PLATE, MARK - STRIPE - L.H

10

206-00-51122

PLATE, MARK - PC220LC MODEL DESIGNATION

11

09690-C0710

PLATE, MARK - KOMATSU NAME - REAR

12

20Y-00-11430

PLATE, CAUTION - KEEP OUT OF SWING RANGE

13

20Y-00-11251

PLATE, MARK - STRIPE - R.H

14

09690-C0315

PLATE, MARK - KOMATSU NAME - SIDE

15

NSS

PLATE, PRODUCT IDENTIFICATION

|$16

01220-60408

SCREW

16

20Y-00-11261

PLATE, MARK - FRONT STRIPE

17

20Y-00-11630

PLATE, HEAT RESISTANT

18

20Y-00-11570

PLATE, MARK - LUBRICATION SERVICE CHART

19

20Y-00-A1260

PLATE, INSTRUCTION - AIR CLEANER

20

205-00-73360

PLATE, HYDRAULIC OIL LEVEL GAUGE

21

20Y-00-11350

PLATE, RUBBER DAMPER CONTACTING AREA

22

09690-M0063

PLATE, MARK

23

205-00-71441

PLATE, INSTRUCTION - ACCUMULATOR INSTALLATION
