Запчасти Komatsu PC220LC-5 МАРКИРОВКА заводской номер A7 THRU A779 - ШАССИ - АНГЛ. МАРКИРОВКА

1

154-54-23260

PAD, ANTI-SKID

2

09669-00002

PLATE, CAUTION - FUEL TANK

3

09650-30104

PLATE, INSTRUCTION - COOLANT OVERFLOW

4

09668-03000

PLATE, SAFETY - RADIATOR CAP REMOVAL

5

20Y-54-12730

PAD, ANTI-SKID

6

09667-03000

PLATE, SAFETY - KEEP HANDS CLEAR OF ENGINE FAN

7

09669-00003

PLATE, CAUTION - HYDRAULIC OIL TANK

8

09653-03000

PLATE, SAFETY - HYDRAULIC TANK CAP REMOVAL

9

20Y-00-11390

PLATE, MARK - STRIPE - L.H

10

206-00-51121

PLATE, MARK - PC220LC MODEL DESIGNATION

11

20Y-00-11142

PLATE, MARK - KOMATSU NAME - REAR

12

20Y-00-11430

PLATE, CAUTION - KEEP OUT OF SWING RANGE

13

20Y-00-11251

PLATE, MARK - STRIPE - R.H

14

09694-50160

PLATE, MARK - KOMATSU LOGO

15

09690-50500

PLATE, MARK - KOMATSU NAME - SIDE

16

NSS

PLATE, PRODUCT IDENTIFICATION

|$17

01220-60408

SCREW

17

20Y-00-11261

PLATE, MARK - FRONT STRIPE

18

20Y-00-11630

PLATE, HEAT RESISTANT

19

20Y-00-11570

PLATE, MARK - LUBRICATION SERVICE CHART

20

20Y-00-A1260

PLATE, INSTRUCTION - AIR CLEANER

21

205-00-73360

PLATE, HYDRAULIC OIL LEVEL GAUGE

22

20Y-00-11350

PLATE, RUBBER DAMPER CONTACTING AREA

23

207-00-31630

PLATE, MARK

24

205-00-71441

PLATE, INSTRUCTION - ACCUMULATOR INSTALLATION
