Запчасти Komatsu PC220-8M0 ТРУБЫ СТРЕЛЫ H [ГИДРАВЛИКА]

1

206-62-D1280

TUBE

2

206-62-27120

TUBE

3

07000-13032

O-RING

4

07000-13032

O-RING

5

07371-30640

FLANGE, SPLIT

6

07372-21035

BOLT

7

01643-51032

WASHER

8

07371-31049

FLANGE, SPLIT

9

07372-21035

BOLT

10

01643-51032

WASHER

11

07372-21040

BOLT

12

01643-51032

WASHER

13

206-62-D2820

CLAMP

14

205-62-73431

SEAT

15

20Y-62-13761

SEAT

|$16

20Y-62-13760

SEAT

16

01010-81235

BOLT

17

01643-31232

WASHER

18

20Y-62-13730

CLAMP

|$20

20Y-62-13740

CLAMP

19

2A5-62-11590

CLAMP

|$22

2A5-62-11580

CLAMP

20

205-62-73431

SEAT

|$24

205-62-73430

SEAT

21

20Y-62-13180

CLAMP

|$26

20Y-62-13220

CLAMP

22

20Y-62-13761

SEAT

|$28

20Y-62-13760

SEAT

23

01010-81235

BOLT

24

20Y-62-13450

PLATE

25

206-62-31722

HOSE

26

07000-13025

O-RING

27

07371-30640

FLANGE, SPLIT

28

07372-21035

BOLT

29

01643-51032

WASHER

30

206-62-31732

HOSE

31

07000-13032

O-RING

32

07371-31049

FLANGE, SPLIT

33

07372-21035

BOLT

34

01643-51032

WASHER
