Запчасти Komatsu PC220-8 РУКОЯТЬ, ВНУТР. ЧАСТИ, ЦИЛИНДР КОВША (№8-) РУКОЯТЬ, MM, ЧАС. СМАЗКА INTERVAL

|$0

707-01-0J900

Cylinder Assembly

1

707-13-14840

Cylinder

2

721-58-10100

Rod, Piston

3

707-76-80431

Bushing

4

07145-00080

Seal, Dust, (Kit : K13)

5

07020-00000

Fitting, Grease

6

707-76-80020

Bushing

7

20Y-70-23230

Seal, Dust, (Kit : K13)

8

07020-00000

Fitting, Grease

9

707-27-14690

Head, Cylinder

10

707-56-10740

Seal, Dust, (Kit : K13)

11

07179-13114

Ring, Snap

12

707-51-10030

Packing, Rod, (Kit : K13)

13

707-51-10650

Ring, Buffer, (Kit : K13)

14

707-52-90781

Bushing

15

07000-15130

O-ring, (Kit : K13)

16

707-35-91420

Ring, Back-up, (Kit : K13)

17

01010-81875

Bolt

18

707-41-11840

Washer

19

707-75-10160

Ring, Snap

20

707-36-14650

Piston

21

707-44-14150

Ring, Piston, (Kit : K13)

22

707-39-14110

Ring, Wear, (Kit : K13)

23

707-44-14910

Ring

24

07000-15090

O-ring, (Kit : K13)

25

07001-05090

Ring, Back-up, (Kit : K13)

26

01310-01216

Screw

27

707-86-67860

Tube

28

07372-21060

Bolt

29

01643-51032

Washer

30

07372-21045

Bolt

31

01643-51032

Washer

32

07000-13030

O-ring, (Kit : K13)

33

707-88-22680

Bracket

34

707-88-21361

Band

35

07372-21035

Bolt

36

01643-51032

Washer

37

01643-31032

Washer

38

01597-01009

Nut

39

07283-32738

Clip, Pipe
