Запчасти Komatsu PC220-8 ЦИЛИНДР КОВША (СИСТЕМА СМАЗКИ 100 ЧАС.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XR870

CYLINDER GROUP

|$3

707-01-0J870

CYLINDER ASS'Y

1

707-13-13880

CYLINDER

2

707-76-80010

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-90E60

ROD,PISTON

5

707-76-80020

BUSHING

6

20Y-70-23230

SEAL,DUST (KIT)

7

707-27-13750

HEAD,CYLINDER

8

07179-13104

RING,SNAP

9

195-63-94170

SEAL,DUST (KIT)

10

707-52-90680

BUSHING

11

707-75-90110

RING,SNAP

12

707-51-90030

PACKING,ROD

13

07000-15120

O-RING (KIT)

14

707-35-91320

RING,BACK-UP (KIT)

15

707-51-90650

RING,BUFFER (KIT)

16

01010-81875

BOLT

17

707-41-11840

WASHER

18

707-36-13780

PISTON

19

707-44-13150

RING,PISTON (KIT)

20

707-39-13150

RING,WEAR (KIT)

21

707-44-13911

RING

22

707-35-90940

RING,BACK-UP (KIT)

23

07000-15080

O-RING (KIT)

24

01310-01216

SCREW

25

07020-00000

FITTING,GREASE

26

07020-00000

FITTING,GREASE

27

707-86-67820

TUBE

28

07372-21060

BOLT

29

01643-51032

WASHER

30

07372-21045

BOLT

31

01643-51032

WASHER

32

07000-13030

O-RING (KIT)

33

707-88-22640

BRACKET

34

707-88-21331

BAND

35

07372-21035

BOLT

36

01643-51032

WASHER

37

07283-32738

CLIP

38

01597-01009

NUT

39

01643-31032

WASHER

|$44

707-98-47720

SERVICE KIT
