Запчасти Komatsu PC220-8 КАБИНА (ПОЛ) (1. УПРАВЛ. НАВЕСН. ОБОРУД.) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

702-16-04290

PILOT VALVE,(SEE FIG. Y1670-21A0)

2

22U-54-25660

SEAL

3

20Y-43-41760

SEAT

4

01010-81025

BOLT

5

01643-31032

WASHER

6

01643-31032

WASHER

7

20Y-62-25360

BRACKET

8

01010-D1035

BOLT

9

01643-71032

WASHER

10

20Y-53-14220

PEDAL

11

01010-D1045

BOLT

12

01643-71032

WASHER

13

22U-54-25541

PLATE

14

01010-81025

BOLT

15

01643-31032

WASHER

16

207-43-81240

CAP

17

20T-910-8660

NIPPLE

18

07000-12011

O-RING

19

20Y-62-52160

ELBOW

20

02896-11008

O-RING

21

07000-12011

O-RING

22

20Y-62-43470

NIPPLE

23

02896-11008

O-RING

24

11Y-62-12140

NIPPLE

25

02896-11008

O-RING

26

07000-12011

O-RING

27

20Y-62-52330

HOSE, 900MM

28

20Y-62-52340

HOSE, 2650MM

29

20Y-62-52350

HOSE, 3350MM

30

208-62-72480

HOSE, 1080MM

31

20Y-62-22790

BAND, RED

32

20Y-62-22810

BAND, YELLOW

33

20Y-62-22820

BAND, BLUE

34

04435-51210

CLIP

35

01583-11408

NUT

36

206-06-61130

SWITCH

37

08193-21012

CLIP

38

08053-01510

CLIP

39

01580-01008

NUT

40

08034-20536

BAND

41

04434-50610

CLIP

42

01580-01008

NUT
