Запчасти Komatsu PC220-7 КОНЕЧНАЯ ПЕРЕДАЧА (ПОСТАВЛЯЕТСЯ ОТДЕЛЬНО) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ]

|$1

206-27-00421

FINAL DRIVE ASS'Y

1

708-8F-00192

MOTOR ASS'Y

|$3

150-27-00410

FLOATING SEAL ASS'Y

2

150-27-00264

SEAL RING ASS'Y

|$5

RING

3

14S2700110

O-RING ASS'Y

|$7

O-RING

4

22U-27-21182

HUB

5

20Y-27-22230

BEARING

6

22U-27-21220

O-RING

7

20Y-27-22261

LOCK

8

20Y-27-22270

LOCK

9

01010-81020

BOLT

10

22U-27-21170

CARRIER

11

22U-27-21140

GEAR

12

20Y-27-22220

BEARING

13

20Y-27-21250

WASHER

14

22U-27-21230

PIN

15

20Y-27-21290

PIN

16

20Y-27-13310

WASHER

17

22U-27-21130

GEAR

18

22U-27-21210

THRUST WASHER

19

22U-27-21152

GEAR

20

22U-27-21161

CARRIER

21

22U-27-21120

GEAR

22

20Y-27-22210

BEARING

23

22U-27-21240

THRUST WASHER

24

20Y-27-21220

PIN

25

20Y-27-21280

PIN

26

22U-27-21110

SHAFT

27

20Y-27-21310

WASHER

28

22U-27-21192

COVER

29

20Y-27-22250

BUTTON

30

20Y-27-13281

BOLT

31

01643-31645

WASHER

32

07049-01012

PLUG

33

07044-12412

PLUG

34

07002-02434

O-RING

35

20Y-27-11582

SPROCKET

36

20Y-27-11561

BOLT
