Запчасти Komatsu PC220-7-AA КЛАПАН PPC(ДЛЯ ХОДА) (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

702-16-01861

PILOT VALVE

1

BODY,VALVE

2

VALVE

3

702-16-51140

SHIM¤ 0.30MM

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-51270

SEAL

9

07000-12020

O-RING

10

702-16-54170

COLLAR

11

702-16-54311

CASE

12

LEVER

13

SHAFT

14

PLATE

15

01010-80855

BOLT

16

01643-30823

WASHER

17

01010-80816

BOLT

18

04025-00432

PIN,SPRING

19

702-16-54430

BUSHING

20

702-16-54331

WASHER¤ 1.60MM

|20

702-16-54341

WASHER¤ 1.30MM

|20

702-16-54351

WASHER¤ 1.00MM

21

702-16-54280

SEAL,DUST

22

702-16-54506

DAMPER ASS'Y

23

01252-60525

BOLT

24

702-16-54511

PLATE

25

04025-00420

PIN,SPRING

26

702-16-54520

LEVER

27

01224-40612

SCREW
