Запчасти Komatsu PC220-7-AA ЦИЛИНДР СТРЕЛЫ(ДЛЯ ПОДЪЕМА РУКОЯТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XY340

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XY350

CYLINDER GROUP,R.H. (FINAL COATING)

|1

707-01-0A350

CYLINDER ASS'Y

1

707-13-13470

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-90930

ROD,PISTON

5

707-76-80431

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-13921

HEAD,CYLINDER

8

07179-13104

RING,SNAP

9

195-63-94170

SEAL,DUST (KIT)

10

707-52-90680

BUSHING

11

707-51-90030

PACKING,ROD (KIT)

12

07000-15120

O-RING (KIT)

13

707-35-91320

RING,BACK-UP (KIT)

14

707-51-90640

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-13780

PISTON

18

707-44-13180

RING,PISTON (KIT)

19

707-39-13150

RING,WEAR (KIT)

20

707-44-13911

RING

21

707-71-60970

PLUNGER

22

07000-15080

O-RING (KIT)

23

707-35-90940

RING,BACK-UP (KIT)

24

01310-01216

SCREW

25

707-71-34630

COLLAR

26

707-35-91320

RING,BACK-UP (KIT)

27

07000-15120

O-RING (KIT)

28

707-86-66290

TUBE,L.H.

|28

707-86-66320

TUBE,R.H.

29

01435-01055

BOLT

30

01435-01040

BOLT

31

07000-13030

O-RING (KIT)

32

707-88-22610

BRACKET,L.H.

|32

707-88-22620

BRACKET,R.H.

33

707-88-21311

BAND

34

01435-01030

BOLT

35

07283-22738

CLIP

36

01599-01011

NUT

37

01643-31032

WASHER

|K

707-99-47790

SERVICE KIT
