СТАРТЕР(.KW)(ВНУТР. ЧАСТИ)

Запчасти Komatsu PC220-6 СТАРТЕР(.KW)(ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ SADE-C ДВИГАТЕЛЬ NO. И UP]

Схема запчастей Komatsu PC220-6 - СТАРТЕР(.KW)(ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ SADE-C ДВИГАТЕЛЬ NO. И UP]
22
39
41
2
4
1
32
23
43
37
29
34
39
40
21
37
14
16
17
19
14
15
13
13
44
36
42
18
12
20
25
24
10
28
27
26
38
33
46
31
5
11
45
7
6
8
9
30
3
35
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

600-863-5110

STARTING MOTORASSEMBLY(5.5KW)

1

ND028100-5410

YOKEASSEMBLY

2

ND028200-5250

ARMATUERASSEMBLY

3

ND949100-3161

BEARINGBALL

|$6

ND949100-5290

BEARINGBALL

4

ND949100-3540

BEARINGBALL

|$8

ND028300-6551

CLUTCHASSEMBLY

5

ND028099-3270

STARTKIT

6

ND028300-6751

CLUTCHASSEMBLY

7

ND949100-4500

BEARINGBALLFRON

8

ND949100-1920

BEARINGBALLREA

9

ND949170-4040

SPRING

10

ND028381-0071

SHAFT

11

ND128401-5621

HOUSING

12

ND153400-2600

MAGNEJICSWITCHASSEMBLY

13

ND028099-5090

KITSTARTER

14

ND028099-5100

KITSTARTER

15

ND053660-0443

PLUNGER

16

ND053404-0240

GASKET

17

ND053505-0290

COVERSOLENOID

18

ND053480-7560

BOLTASSE'YTERMINAL

19

ND949047-4440

BOLT

20

ND028065-0250

BUSHINGDRAIN

21

ND028510-0880

BRUSHHOLDERASSEMBLY

22

ND028520-0011

SPRING

23

ND028501-7711

FLAME

24

ND949120-0240

BALL

25

ND949170-4070

SPRING

26

ND028371-3210

PINIONSTARTER

27

ND028306-0070

ROLLERCLUTCH

28

ND028063-0030

RETAINER

29

ND028062-0130

COVER

30

ND949042-3680

BOLT

31

ND90801-10050

O-RING

32

ND949042-3690

BOLT

33

ND949006-4720

SCREW

34

ND949056-4480

NUT

35

ND028327-0171

RETAINERSNAP

36

ND90258-10001

WASHERSPRING

37

ND028901-0361

SEAL

38

ND028371-3200

PINION

39

ND949007-6530

SCREW

40

ND028530-1090

BRUSHASS'Y

41

ND028530-1100

BRUSH ASS'Y

42

ND949007-6850

SCREW

43

ND028062-5790

COVER

44

ND90170-10061

NUT

45

ND90801-20470

O-RING

46

ND90200-06241

WASHER
