Запчасти Komatsu PC220-6 FULE ТОПЛ. НАСОС(РЕГУЛЯТОР)(/)(ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ SADE-C ДВИГАТЕЛЬ NO. И UP]

|$1

6736-71-1131

INJECTIONPUMPASSEMBLY

|$4

DK105404-5240

GOVERNORASSEMBLY

1

DK154620-0200

HOUSING

2

DK154007-2900

PLUG

3

DK154620-3200

GASKET

4

DK154620-1400

COVER

5

DK020006-1640

BOLT

6

DK154620-4600

BOLT

7

DK154620-5600

WASHER

8

DK154620-7900

ADAPTE

9

DK154375-9020

PLATE

10

DK029010-6810

BOLT

11

DK020106-1840

BOLT

12

DK154010-0100

SCREW

13

DK154011-0100

NUTLOCK

14

DK029632-5070

O-RING

15

DK155404-5120

LIMITER

16

DK026518-2240

GASKET

17

DK154621-2120

FLYWEIGHTASSEMBLY

18

DK029321-2020

WASHERSPRING

19

DK029231-2030

NUT

20

DK154123-0120

SLEEVE

21

DK029311-0010

SHIM0.20MM

|$27

DK029311-0180

SHIM0.30MM

|$28

DK029311-0190

SHIM0.40MM

|$29

DK139410-0000

SHIM0.50MM

|$30

DK139410-0210

SHIM1.00MM

|$31

DK139410-0100

SHIM1.50MM

|$32

DK139410-3000

SHIM2.00MM

|$33

DK139410-3100

SHIM3.00MM

|$34

DK139410-3200

SHIM4.00MM

22

DK15454-5200

SPRING

23

DK154211-4420

GUIDELEVERASSEMBLY

24

DK154620-2520

LINK

25

DK016010-0540

RINGSNAP

26

DK154236-4100

LEVER

27

DK154390-0000

GASKET

28

DK154620-8700

PLUG

29

DK154620-3100

GASKET

30

DK154620-8800

PIN

31

DK154620-8900

PLATE

32

DK010038-1840

BOLT

33

DK154620-1300

FLANGE

34

DK154620-4700

BOLT

35

DK014110-8440

WASHER SPRING

36

DK014010-8140

WASHER

37

DK154620-9000

O-RING
