Запчасти Komatsu PC220-6 FULE ТОПЛ. НАСОС(НАСОС)(/)(ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ SADE-C ДВИГАТЕЛЬ NO. И UP]

|$1

6736-71-1131

INJECTIONPUMPASSEMBLY

|$4

DK101061-9990

PUMPASSEMBLY

1

DK131073-9120

HOUSING

2

DK029040-6020

STU

3

DK134026-0000

PLU

4

DK131002-2000

ADAPTE

5

DK131028-6020

COVER

6

DK131011-0800

GASKE

7

DK131017-1000

SCREW

8

DK029340-6020

GASKET

9

DK139206-0400

NUT

10

DK029633-1010

O-RING

11

DK131371-4600

CAMSHAFT

12

DK016630-2030

BEARING

|$18

DK028201-7020

BEARING

13

DK016640-2030

BEARING

|$20

DK028202-0020

BEARING

14

DK131302-1300

RING

15

DK131302-1700

RING

16

DK029-312-0310

SHIM0.10MM

|$24

DK029312-0320

SHIM0.12MM

|$25

DK029312-0330

SHIM0.14MM

|$26

DK029312-0340

SHIM0.16MM

|$27

DK029312-0350

SHIM0.18MM

|$28

DK029312-0360

SHIM0.3MM

|$29

DK029312-0370

SHIM0.5MM

|$30

DK029312-0380

SHIM1.0MM

17

DK029311-7010

SHIM0.1MM

|$32

DK029311-7020

SHIM0.12MM

|$33

DK029311-7030

SHIM0.14MM

|$34

DK029311-7040

SHIM0.16MM

|$35

DK029311-7050

SHIM0.18MM

|$36

DK029311-7090

SHIM0.3MM

|$37

DK029311-7060

SHIM0.5MM

|$38

DK029311-7210

SHIM0.7MM

|$39

DK029311-7070

SHIM1.0MM

|$40

DK029311-7220

SHIM1.4MM

|$41

DK139417-0000

SHIM2.40MM

18

DK131306-1000

BEARINGCENTER

19

DK029050-5010

SCREW

20

DK026505-0940

GASKET

21

DK029622-0190

SEALOIL

22

DK131330-6400

COVER

23

DK029010-6810

BOLT

24

DK131321-1900

GASKET

25

DK131424-3420

VALVE

26

DK131401-0020

BOLTEYE

27

DK029341-4130

GASKET

28

DK029637-5020

O-RING

29

DK029731-0120

BOLTEYE

30

DK029341-0110

GASKET
