Запчасти Komatsu PC220-6 ГЛАВН. КЛАПАН Y [РЕМ. КОМПЛЕКТЫ]

Схема запчастей Komatsu PC220-6 - ГЛАВН. КЛАПАН Y [РЕМ. КОМПЛЕКТЫ]
21
22
34
31
13
4
7
5
33
1
31
6
8
32
14
18
29
28
27
30
24
26
15
20
36
35
37
31
2
3
12
9
19
16
17
25
46
48
39
40
45
23
38
41
42
43
47
44
11
10

Артикул

Название

Примечание

Количество

|$1

702-21-09147

VALVEASS'Y

|$2

702-21-09146

VALVEASS'Y

|$3

702-21-09145

VALVEASS'Y

|$4

702-21-09143

VALVEASS'Y

2

702-21-55310

VALVE

3

702-21-55460

SPRING

4

702-21-55420

O-RING

5

702-21-55520

O-RING

5

702-21-55430

O-RING

6

702-21-55440

O-RING

7

702-21-53120

FILTER

8

07000-11009

O-RING

9

702-21-55410

PLATE

10

01252-60820

BOLT

11

01643-50823

WASHER

12

702-21-55530

O-RING

12

702-21-55150

O-RING

18

702-21-55640

SPRING

19

702-21-55660

WASHER

21

702-21-55620

PLUG

22

07002-11423

O-RING

24

07000-11009

O-RING

26

07992-11623

O-RING

27

702-21-55710

SEAT

28

702-21-55720

SPRING

29

04260-00793

BALL

30

07000-11009

O-RING

32

702-21-55670

ORIFICE

33

702-21-55470

ORIFICE

34

01252-60520

BOLT

35

702-21-55480

FLNAGE

36

07000-12020

O-RING

37

01252-61025

BOLT

|$44

702-21-55100

RELIEFVALVEASS'Y

46

702-16-53920

O-RING

48

07002-11623

O-RING

Выбрано товаров: 36
