Запчасти Komatsu PC220-6 МОТОР ПОВОРОТА (/)(№-7) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-75-01101

MOTOR ASS'Y

|1

706-75-01100

MOTOR ASS'Y

|1

706-75-03022

MOTOR SUB ASS'Y

|1

706-75-03021

MOTOR SUB ASS'Y

1

07000-05200

O-RING

2

01252-61440

BOLT

|2

706-87-50360

BOLT

3

706-75-42662

SHAFT

|3

706-75-42661

SHAFT

4

706-75-42880

BEARING

5

706-76-40890

BEARING

6

706-7E-11260

SPRING

7

706-7E-11270

SEAT

8

706-75-05010

SPACER KIT

|8

SPACER¤ 5.0MM

|8

SPACER¤ 5.4MM

|8

SPACER¤ 5.8MM

9

04064-04518

RING,SNAP

10

706-7E-11280

SEAL

11

706-75-42711

COVER

12

07000-02085

O-RING

13

04065-09030

RING,SNAP

14

706-75-41091

BLOCK,CYLINDER

15

706-75-42740

PLATE,VALVE

16

04020-00820

PIN

17

706-75-42180

SHAFT,CENTER

18

706-75-41130

RING,CENTER

19

706-75-41220

BALL,CENTER

20

706-75-41110

SPRING

|21

706-75-05020

RETAINER KIT

21

RETAINER

22

SCREW

23

706-75-41163

PISTON SUB ASS'Y

24

706-75-92130

PLATE

25

706-75-92141

PLATE

|25

706-75-92140

PLATE

26

706-75-92150

DISK

27

706-75-92180

PISTON,BRAKE

28

07000-15155

O-RING

29

07000-15175

O-RING

30

706-75-92170

SPRING

|30

706-75-92160

SPRING
