Запчасти Komatsu PC220-6 МОТОР ХОДА (/)(№-77) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-8H-00181

MOTOR ASS'Y

|$4

708-8H-04611

CASE SUB ASS'Y

1

CASE,MOTOR

2

PLUG

3

708-8H-31210

O-RING

|$8

708-8H-04622

END COVER SUB ASS'Y

4

COVER,END

5

SPOOL

6

SPOOL

7

PLUG

8

708-8E-14110

PLUG

9

07002-11023

O-RING

10

04260-00793

BALL

11

708-8H-34170

SPRING

12

708-8H-34210

SEAT

13

708-8H-34180

RING

14

708-8H-36140

PISTON

15

708-8H-36121

SPRING

16

708-8H-16141

PLUG

17

07002-13634

O-RING

18

706-73-72420

VALVE

19

706-73-72440

SPRING

20

708-8H-36150

PLUG

21

07000-12018

O-RING

22

07001-02018

RING,BACK-UP

23

708-8H-11530

PLUG

24

07002-11423

O-RING

25

20B-27-11210

BLEEDER

26

01252-62055

BOLT

27

01252-62095

BOLT

28

07000-12012

O-RING

29

708-8E-16180

VALVE

30

708-8E-16160

PLUG

31

07002-11023

O-RING

32

708-18-13230

PIN

33

706-75-42820

PIN,DOWEL

34

708-8E-16180

VALVE

35

708-8E-16160

PLUG

36

07002-11023

O-RING

37

04020-01228

PIN

38

04260-02857

BALL

39

708-8H-34142

PISTON

40

708-8H-34151

SPRING

41

708-8K-14210

PLUG

42

07002-13334

O-RING
