Запчасти Komatsu PC220-6 ЦИЛИНДР РУКОЯТИ(№8-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XX920

ARM CYLINDER GROUP,(FINAL COATING)

G-1

206-63-X9030

ARM CYLINDER GROUP

G-1

206-63-X3121

ARM CYLINDER GROUP

G-1

206-63-X3120

ARM CYLINDER GROUP

|$8

707-01-0E580

CYLINDER ASS'Y

|$9

206-63-03121

CYLINDER ASS'Y

|$10

206-63-03120

CYLINDER ASS'Y

1

206-63-64741

CYLINDER

1

206-63-64740

CYLINDER

2

707-76-80010

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-10840

ROD,PISTON

4

206-63-64720

ROD,PISTON

5

707-27-14920

HEAD,CYLINDER

6

07179-13114

RING,SNAP

7

176-63-56170

SEAL,DUST (KIT)

8

707-52-90780

BUSHING

9

707-51-10030

PACKING,ROD (KIT)

10

07000-15130

O-RING (KIT)

11

707-35-91420

RING,BACK-UP (KIT)

12

707-51-10630

RING,BUFFER (KIT)

13

01010-81875

BOLT

14

707-41-11840

WASHER

15

707-36-14410

PISTON

16

707-44-14180

RING,PISTON (KIT)

17

707-39-14820

RING,WEAR (KIT)

18

707-44-14910

RING

19

707-71-61050

PLUNGER

20

07000-15090

O-RING (KIT)

21

07001-05090

RING,BACK-UP (KIT)

22

01310-01216

SCREW

23

707-71-60230

PLUNGER

24

07020-00900

FITTING,GREASE

25

707-71-32780

COLLAR

26

707-35-91420

RING,BACK-UP (KIT)

27

07000-15130

O-RING (KIT)

28

04260-00635

BALL

29

707-71-91270

CAP

29A

707-83-13010

VALVE

29B

07750-01628

SPRING

29C

707-87-14070

PLUG

29D

07002-12034

O-RING (KIT)

30

206-63-64770

TUBE

31

20D-62-17860

ELBOW

32

01435-01055

BOLT

33

01435-01040

BOLT

34

07000-13030

O-RING (KIT)

35

01010-81080

BOLT

36

01643-31032

WASHER

37

07000-13035

O-RING (KIT)

38

707-88-95401

BRACKET

39

707-88-95380

BAND

40

01010-81035

BOLT

41

01643-51032

WASHER

42

707-88-11560

PLATE

43

07283-22738

CLIP

44

01599-01011

NUT

45

01643-31032

WASHER
