Запчасти Komatsu PC210NLC-8K МОТОР ХОДА (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC210NLC-8K - МОТОР ХОДА (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31

Артикул

Название

Примечание

Количество

|1

708-8F-00250

MOTOR ASSEMBLY

1

708-8F-32121

SHAFT

2

708-8F-12151

BEARING

3

708-7L-12140

BEARING

4

708-7L-05010

SPACER KIT

|4

SPACER, 1.5MM

|4

SPACER, 1.6MM

|4

SPACER, 1.7MM

|4

SPACER, 1.8MM

|4

SPACER, 1.9MM

|4

SPACER, 2.0MM

5

706-7G-11291

SEAL, OIL

6

708-8F-12230

SPACER, 3.2MM

7

04065-07225

RING, SNAP

8

BLOCK, CYLINDER

9

PLATE, VALVE

10

PIN

11

708-8F-33360

PIN

12

708-7L-13140

SEAT

13

708-8F-33160

SPRING

14

04065-04818

RING, SNAP

15

708-8F-33350

GUIDE, RETAINER

16

708-2L-33350

RETAINER, SHOE

|16

708-8F-33340

RETAINER, SHOE

17

708-8F-33310

PISTON SUB ASSEMBLY

18

708-8F-33481

CAM, ROCKER

19

708-8F-33710

BALL, RETAINER

20

708-8F-34141

PISTON

21

708-8F-34150

SPRING

22

708-8F-35220

PLATE

23

708-8F-35230

PLATE

24

708-8F-35120

DISC

25

708-8F-35140

PISTON, BRAKE

26

708-8F-35160

O-RING

27

708-8F-35170

RING, BACK-UP

28

708-8F-35180

O-RING

29

708-8F-35190

RING, BACK-UP

30

708-8F-35150

SPRING

31

04025-00324

PIN, SPRING

Выбрано товаров: 39
