Запчасти Komatsu PC210NLC-8K МОТОР ПОВОРОТА (/) (№K-K) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-7G-01041

MOTOR ASSEMBLY

|1

706-7G-03041

MOTOR SUB ASSEMBLY

1

706-7G-41610

SHAFT, DRIVE

2

706-75-42880

BEARING

3

706-75-43810

SPACER

4

706-7E-11260

SPRING

5

706-7E-11270

SEAT

6

706-76-40890

BEARING

7

706-75-05040

SPACER KIT

|7

SPACER, 3.1MM

|7

SPACER, 3.4MM

|7

SPACER, 3.7MM

8

04064-04518

RING, SNAP

9

706-7E-11280

SEAL, OIL

10

706-75-43720

SPACER

11

04065-06220

RING, SNAP

12

706-7G-41210

BLOCK, CYLINDER

13

706-7G-41710

PLATE, VALVE

14

706-75-43750

PIN, DOWEL

15

706-7G-41120

SHAFT, CENTER

16

706-7G-41130

RING, CENTER

17

706-7G-41140

SPRING

|18

706-7G-05010

RETAINER KIT

18

RETAINER

19

SCREW

20

706-7G-41160

PISTON SUB ASSEMBLY

21

706-7G-91340

PLATE

22

706-7G-91350

DISC

23

706-7G-91111

PISTON, BRAKE

24

706-77-40370

O-RING

25

708-8F-31610

O-RING

26

706-7G-91360

SPRING
