Запчасти Komatsu PC210NLC-8K МОТОР ПОВОРОТА (/) (№K-K) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-7G-01130

MOTOR ASSEMBLY

|1

706-7G-03090

MOTOR SUB ASSEMBLY

1

706-7G-41630

SHAFT, DRIVE

2

706-75-42880

BEARING

3

706-7G-41660

SPACER

4

706-76-40890

BEARING

5

706-7G-41510

SPACER KIT

|5

SPACER, T=3.1MM

|5

SPACER, T=3.4MM

|5

SPACER, T=3.7MM

6

04064-04518

RING, SNAP

7

706-7E-11280

SEAL, OIL

8

706-7G-41910

SPACER

9

04065-06220

RING, SNAP

10

706-7G-41310

BLOCK, CYLINDER

11

706-7G-41720

PLATE, VALVE

12

706-75-43750

PIN, DOWEL

13

706-7G-41320

SHAFT, CENTER

14

706-7G-41130

RING, CENTER

15

706-7G-41140

SPRING

|16

706-7G-05010

RETAINER KIT

16

RETAINER

17

SCREW

18

706-7G-41410

PISTON SUB ASSEMBLY

19

706-7G-91441

PLATE

20

706-7G-91450

DISC

21

706-7G-91120

PISTON, BRAKE

22

706-75-92310

O-RING

23

708-8F-31610

O-RING

24

706-7G-91360

SPRING
