Запчасти Komatsu PC210NLC-7K ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC210NLC-7K - ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
2
3
3
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17
18
18
19
20
21
21
22
23
24
25
26
26
27
28
29
29A
29B
29C
29D
30
31
32
33
34
35
36
37
38
39
40
41
41
42
42
43
43
44
45
46
47
48
49
50
51

Артикул

Название

Примечание

Количество

G1

707-01-XY441

CYLINDER GROUP

G1

707-01-XY440

CYLINDER GROUP

|1

707-01-0A311

CYLINDER ASS'Y

|1

707-01-0A310

CYLINDER ASS'Y

1

707-13-13540

CYLINDER

2

707-76-80470

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-95162

ROD,PISTON

|4

707-58-95161

ROD,PISTON

5

707-27-13961

HEAD,CYLINDER

6

07179-13109

RING,SNAP

7

707-56-95510

SEAL,DUST (KIT)

8

707-52-90720

BUSHING

9

707-51-95030

PACKING,ROD (KIT)

10

07000-15125

O-RING (KIT)

11

707-35-91370

RING,BACK-UP (KIT)

12

707-51-95640

RING,BUFFER (KIT)

13

01010-81875

BOLT

14

707-41-11840

WASHER

15

707-36-13771

PISTON

16

707-44-13280

RING,PISTON (KIT)

17

707-39-13530

RING,WEAR (KIT)

18

707-44-13920

RING

19

707-71-61070

PLUNGER

20

07000-15085

O-RING (KIT)

21

707-35-90960

RING,BACK-UP (KIT)

22

01310-01216

SCREW

23

707-71-70270

PLUNGER

24

07020-00000

FITTING,GREASE

25

707-71-32770

COLLAR

26

707-35-91370

RING,BACK-UP (KIT)

27

07000-15125

O-RING (KIT)

28

04260-00635

BALL

29

707-71-91270

CAP

29A

707-83-13010

VALVE

29B

07750-01628

SPRING

29C

707-87-14070

PLUG

29D

07002-12034

O-RING (KIT)

30

707-86-66270

TUBE

31

20D-62-17860

ELBOW

32

01435-01055

BOLT

33

01435-01040

BOLT

34

07000-13030

O-RING (KIT)

35

01435-01075

BOLT

36

07000-13035

O-RING (KIT)

37

707-88-22530

BRACKET

38

707-88-21261

BAND

39

01435-01030

BOLT

40

707-88-11560

PLATE

41

07283-22738

CLIP

42

01599-01011

NUT

43

01643-31032

WASHER

44

01643-51032

WASHER,(FOR SHIPPING)

45

07372-21035

BOLT,(FOR SHIPPING)

46

707-88-33030

HEAD,(FOR SHIPPING)

47

07371-30640

FLANGE,(FOR SHIPPING)

48

01643-51032

WASHER,(FOR SHIPPING)

49

07372-21035

BOLT,(FOR SHIPPING)

50

707-88-33040

CAP,(FOR SHIPPING)

51

07371-31049

FLANGE,(FOR SHIPPING)

K

707-99-57160

SERVICE KIT

Выбрано товаров: 61
