Запчасти Komatsu PC210MH-8 ЦИЛИНДР КОВША ( M ПРЯМ. РУКОЯТЬ) TABLE OF CONTENTS PCMH-8

|$1

707-01-XR270

CYLINDER GROUP

|$2

707-01-XJ270

CYLINDER ASSEMBLY

1

707-01-XH740

CYLINDER

|1

707-13-11560

CYLINDER

2

707-76-70120

BUSHING

|2

707-76-70690

BUSHING

3

07145-00070

SEAL, DUST

4

707-58-80870

ROD, PISTON

|4

707-58-80651

ROD PISTON

5

707-76-70120

BUSHING

|5

707-76-70690

BUSHING

6

20Y-70-23220

SEAL, DUST

7

707-51-11870

HEAD, CYLINDER

|7

707-27-11981

HEAD, CYLINDER

8

07179-13904

RING, SNAP

9

195-63-92190

SEAL, DUST

|9

707-56-92190

SEAL, DUST

10

707-52-90560

BUSHING

11

707-51-80030

PACKING, ROD

12

707-35-91150

O-RING

|12

07000-15105

O-RING

13

707-35-91150

RING, BACK-UP

14

707-51-80650

RING, BUFFER

|14

707-51-80640

RING, BUFFER

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-11880

PISTON

|17

707-36-11851

PISTON

18

707-44-11250

RING, PISTON

|18

707-44-11280

RING, PISTON

19

707-39-11530

RING, WEAR

20

707-44-11920

RING

21

707-35-90360

RING BACK-UP

22

07000-15070

O-RING

23

01310-01216

SCREW

24

07020-00000

FITTING, GREASE

|24

07000-00000

FITTING, GREASE

25

07020-00000

FITTING, GREASE

|25

07000-00000

FITTING, GREASE

26

707-86-67750

TUBE

|26

707-86-66280

TUBE

27

07375-21060

BOLT

|27

01435-01055

BOLT

28

07375-21040

BOLT

|28

01435-01040

BOLT

29

07000-13030

O-RING

30

707-88-22570

BRACKET

31

707-88-21271

BAND

32

07375-21035

BOLT

|32

01435-01030

BOLT

33

07283-32738

CLIP

|33

07283-22738

CLIP

34

01597-01009

NUT

|34

01599-01011

NUT

35

01643-31032

WASHER

36

707-88-33030

HEAD

37

07371-30640

FLANGE

38

07372-21035

BOLT

39

01643-51032

WASHER
