Запчасти Komatsu PC210MH-8 ТРУБЫ - M ПРЯМ. РУКОЯТЬ TABLE OF CONTENTS PCMH-8

1

20K-970-KA80

DDC TUBE

2

20K-970-KA90

DDC TUBE

3

20K-970-KB10

DDC TUBE

4

20K-970-KB20

DDC TUBE

5

20K-970-KB30

DDC TUBE

6

20Y-62-87290

PLATE

7

01024-81230

BOLT SEMS

8

20Y-970-2301

DDC VALVE ASSEMBLY

9

01024-81230

BOLT SEMS

10

20K-970-KB60

FLANGE

11

07000-13035

O-RING

12

01252-71025

BOLT

13

07371-30640

FLANGE (DLF)

14

07378-10600

HEAD

15

07000-13025

O-RING

16

07375-21035

BOLT

17

207-62-66540

FLANGE

18

07000-13032

O-RING

19

01252-71030

BOLT

20

07371-30500

FLANGE

21

07378-10500

HEAD

22

07000-13022

O-RING

23

01010-80830

BOLT (DLF)

24

01643-50823

WASHER

25

07375-21040

BOLT SEMS

26

07000-13032

O-RING

27

07020-00675

FITTING

28

07214-50813

CONNECTOR

29

20K-70-KA310

DDC TUBE

30

20K-70-KA320

DDC TUBE

31

20K-70-KA330

DDC TUBE

32

01024-81220

BOLT SEMS

33

04434-51010

CLIP

34

20Y-25-11270

ELBOW

35

20Y-70-11540

NIPPLE

36

KVX-5X-02350

COUPLING

37

20Y-81-8K560

push in straight connector

38

20Y-81-8K590

80 mtr hose grease filled

39

20Y-81-8K550

FITTING

40

20Y-81-8K580

Stud (432-24162-1)

41

20Y-81-8K570

STUD

42

02896-11009

O-RING
