Запчасти Komatsu PC210MH-8 .8M СТРЕЛА (УПЛОТНЕНИЕ И ПАЛЕЦ ) (ДЛЯ .M РУКОЯТЬ) TABLE OF CONTENTS PCMH-8

1

20Y-70-KC611

BOOM

|1

20Y-70-KC610

BOOM

2

07145-00090

DUST SEAL

3

20Y-70-31512

BUSHING

|3

20Y-70-31511

BUSHING

4

20Y-70-31253

PIN

5

20Y-70-31372

SPACER, T=2.0MM

|5

20Y-70-31371

SPACER, T=2.0MM

6

20Y-70-31521

SPACER, T=2.5MM

|6

20Y-70-31520

SPACER, T=2.5MM

7

20Y-70-31531

SPACER, T=3.0MM

|7

20Y-70-31530

SPACER, T=3.0MM

8

205-70-71312

PLATE

9

01010-81235

BOLT

10

01643-31232

WASHER

11

205-70-71210

PIN

12

205-70-66580

PLATE

13

01010-81235

BOLT

14

01643-31232

WASHER

15

21K-70-71640

SPACER, T=2.0MM

|15

20Y-70-31391

SPACER, T=2.0MM

|15

20Y-70-31390

SPACER, T=2.0MM

16

21K-70-71630

SPACER, T=1.0MM

|16

20Y-70-31381

SPACER, T=1.0MM

|16

20Y-70-31380

SPACER, T=1.0MM

17

206-70-21210

PIN

18

20Y-70-31430

SPACER, T=1.0MM

19

206-70-71531

SPACER, T=2.0MM

|19

206-70-71530

SPACER, T=2.0MM

20

20Y-70-41221

PLATE

21

01010-81640

BOLT

22

01643-31645

WASHER

23

206-70-71521

SPACER, T=1.0MM

|23

206-70-71520

SPACER, T=1.0MM
