Запчасти Komatsu PC210MH-8 ЦИЛИНДР РУКОЯТИ TABLE OF CONTENTS PCMH-8
6
6
5
4
8
9
12
7
15
10
11
14
13
26
27
28
27
17
16
46
48
49
50
51
47
3
2
3
37
38
57
58
40
41
35
43
56
42
45
44
1
39
36
25
21
20
18
19
20
21
24
23
24
22
52
53
55
54
34
29
33
32
30
31
G-1
707-01-XS790
CYLINDER ASSEMBLY (LH)
|1
707-01-XS800
CYLINDER ASSEMBLY (RH)
1
707-01-XS430
CYLINDER (LH)
|1
707-01-XS440
CYLINDER (RH)
2
707-76-80431
BUSHING
3
07145-00080
SEAL
4
707-58-95280
ROD
5
707-76-80431
BUSHING
6
07145-00080
SEAL
7
707-27-13850
HEAD
8
07179-13109
RING
9
707-56-95510
SEAL
10
707-52-90721
BUSHING
11
707-75-95030
RING
12
707-51-95030
PACKING
13
07000-15125
O-RING
14
707-35-91370
RING
15
707-51-95650
RING
16
01010-81875
BOLT
17
707-41-11840
WASHER
18
707-36-13771
PISTON
19
707-44-13250
RING
20
707-39-13530
RING
21
707-44-13920
RING
22
707-71-71010
PLUNGER
23
07000-15085
O-RING
24
707-35-90960
RING
25
01310-01216
SCREW
26
707-71-35010
COLLAR
27
707-35-91370
RING
28
07000-15125
O-RING
29
707-86-67850
DDC TUBE (RH)
|29
206-62-73450
DDC TUBE (LH)
30
07372-21060
BOLT
31
01643-51032
WASHER
32
07372-21045
BOLT
33
01643-51032
WASHER
34
07000-13030
O-RING
35
707-88-28160
BRACKET
36
707-88-21621
BAND
37
07372-21035
BOLT
38
01643-51032
WASHER
39
07283-32738
CLIP
40
01597-01009
NUT
41
01643-31032
WASHER
42
20Y-62-KB360
DDC TUBE (LH)
|42
20Y-62-KB370
DDC TUBE (RH)
43
07000-13030
O-RING
44
07372-21035
BOLT
45
01643-51032
WASHER
46
702-21-08330
PILOT VALVE
47
07000-13030
O-RING
48
07375-21050
BOLT
49
01643-51032
WASHER
50
07375-21060
BOLT
51
01643-51032
WASHER
52
707-88-33030
HEAD
53
07371-30640
FLANGE
54
07375-21035
BOLT
55
01643-51032
WASHER
56
07283-32738
CLIP
57
01597-01009
NUT
58
01643-31032
WASHER
