Запчасти Komatsu PC210MH-8 ЦИЛИНДР СТРЕЛЫ TABLE OF CONTENTS PCMH-8

G-1

707-01-XR740

CYLINDER ASSEMBLY LH

|G-1

707-01-XR750

CYLINDER ASSEMBLY RH

1

707-01-XS830

CYLINDER G. (LH)

|1

707-01-XS840

CYLINDER G. (RH)

2

707-76-80431

BUSHING

3

07145-00080

SEAL

4

707-58-95280

ROD

5

707-76-80431

BUSHING

6

07145-00080

SEAL

7

707-27-13850

HEAD

8

07179-13109

RING

9

707-56-95510

SEAL

10

707-52-90721

BUSHING

11

707-75-95030

RING

12

707-51-95030

PACKING

13

07000-15125

O-RING

14

707-35-91370

RING

15

707-51-95650

RING

16

01010-81875

BOLT

17

707-41-11840

WASHER

18

707-36-13771

PISTON

19

707-44-13250

RING

20

707-39-13530

RING

21

707-44-13920

RING

22

707-71-71010

PLUNGER

23

07000-15085

O-RING

24

707-35-90960

RING

25

01310-01216

SCREW

26

707-71-35010

COLLAR

27

707-35-91370

RING

28

07000-15125

O-RING

29

206-62-73450

DDC TUBE (LH)

29

707-86-67850

DDC TUBE (RH)

30

07372-21060

BOLT

31

01643-51032

WASHER

32

07372-21045

BOLT

33

01643-51032

WASHER

34

07000-13030

O-RING

35

707-88-28160

BRACKET

36

707-88-21621

BAND

37

07372-21035

BOLT

38

01643-51032

WASHER

39

07283-32738

CLIP

40

01597-01009

NUT

41

01643-31032

WASHER

42

206-62-73450

DDC TUBE (LH)

42

206-62-73460

DDC TUBE (RH)

43

07000-13030

O-RING

44

07375-21035

BOLT

45

01643-51032

WASHER

46

702-21-08330

VALVE ASSEMBLY

47

07000-13030

O-RING

48

07375-21050

BOLT

49

01643-51032

WASHER

50

07375-21060

BOLT

51

01643-51032

WASHER

52

707-88-33030

HEAD

53

07371-30640

FLANGE

54

07375-21035

BOLT

55

01643-51032

WASHER

56

07283-32738

CLIP

57

01597-01009

NUT

58

01643-31032

WASHER
