Запчасти Komatsu PC210MH-8 .8M СТРЕЛА (СТРЕЛА И LUBE ТРУБЫ) TABLE OF CONTENTS PCMH-8

1

20Y-25-11270

ELBOW

2

20Y-70-31310

TUBE

3

20Y-70-31320

TUBE

4

20Y-70-11540

NIPPLE

5

07020-00000

FITTING

6

04434-52212

CLIP

7

01024-81220

BOLT SEMS

|7

01010-81220

BOLT

|7

01643-31232

WASHER

8

20Y-62-KA850

TUBE

9

04434-51010

CLIP

10

01024-81220

BOLT SEMS

|10

01010-81220

BOLT

|10

01643-31232

WASHER

11

KV-X5X0-7080

UNION

12

20Y-70-11520

HOSE

13

20Y-62-KA840

TUBE

14

04434-51612

CLIP

15

01024-81220

BOLT SEMS

|15

01010-81220

BOLT

|15

01643-31232

WASHER

16

20Y-62-KA870

TUBE

17

20Y-62-KA880

TUBE

18

20Y-818-K590

HOSE

19

20Y-818-K570

SLEEVE

20

20Y-818-K580

STUD

21

20Y-818-K560

CONNECTOR

22

KV-X5X0-2350

COUPLING

23

20Y-70-11540

NIPPLE

24

20Y-62-KA860

TUBE

25

20Y-62-KA890

TUBE

26

20Y-818-K550

CONNECTOR

27

205-70-51390

NIPPLE

28

20Y-62-KA740

TUBE

29

20Y-62-KA810

TUBE

30

20Y-62-KA720

TUBE

31

20Y-62-KA780

TUBE

32

20Y-62-KA710

TUBE

33

20Y-62-KA770

TUBE

34

20Y-62-KA730

TUBE

35

20Y-62-KA790

TUBE

36

20Y-62-KA760

TUBE

37

20Y-62-KA830

TUBE

38

20Y-62-KA750

TUBE

39

20Y-62-KA820

TUBE

40

20Y-62-KA670

TUBE

41

20Y-62-KA680

TUBE

42

20Y-62-KA640

TUBE

43

20Y-62-KA630

TUBE
