Запчасти Komatsu PC210MH-8 ОСНОВН. КОНСТРУКЦИЯ (OPERATORґS КАБИНА) (УПРАВЛ. НАВЕСН. ОБОРУД.) ( ATT) TABLE OF CONTENTS PCMH-8

1

207-62-KD560

BRACKET

2

20G-60-K1301

VALVE ASSEMBLY

3

207-06-KA520

WIRING HARNESS

4

01010-81065

BOLT

5

01643-31032

WASHER

6

08053-01510

CLIP

7

02782-10210

ELBOW

8

02896-11008

O RING

9

07002-11423

O-RING

10

02782-10212

ELBOW

11

02896-11008

O RING

12

07002-11423

O-RING

25

02760-00211

HOSE

26

02760-00212

HOSE

27

20Y-62-85670

HOSE, 5800MM

28

20Y-62-85680

HOSE, 5750MM

29

20Y-62-22790

BAND, RED

30

20Y-62-22810

BAND, YELLOW

31

20Y-62-22820

BAND, BLUE

32

20Y-62-22830

BAND, WHITE

33

08034-00519

BAND

34

21W-62-42240

HOSE

35

04435-51210

CLIP

36

01583-51408

NUT

37

702-21-07010

VALVE ASSEMBLY

38

203-60-62220

BOLT

39

700-93-11320

O-RING

40

07000-12011

O-RING

41

20Y-62-43410

BLOCK

42

01010-80820

BOLT

43

01643-30823

WASHER

44

20Y-62-43420

BRACKET

45

02782-10210

ELBOW

46

02896-11008

O-RING

47

07002-11423

O-RING

48

21W-62-43960

ELBOW

49

02896-11008

O-RING

50

07002-11423

O-RING

51

08053-01510

CLIP
