Запчасти Komatsu PC210LC-8K КОНЕЧНАЯ ПЕРЕДАЧА (STD) (LC) (№K77) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|1

20Y-27-00560

FINAL DRIVE ASSEMBLY

|1

20Y-27-00110

FLOATING SEAL A.

1

SEAL

2

O-RING

3

20Y-27-42520

HUB

4

20Y-27-41260

BEARING

5

20Y-27-22280

O-RING

6

20Y-27-41190

NUT, LOCK

7

20Y-27-41180

LOCK

8

01010-81020

BOLT

9

20Y-27-42540

CARRIER

10

20Y-27-22140

GEAR

11

20Y-27-22220

BEARING

12

20Y-27-21250

THRUST WASHER

13

20Y-27-21230

PIN

14

20Y-27-21290

PIN

15

20Y-27-13310

THRUST WASHER

16

20Y-27-22130

GEAR

17

20Y-27-22240

THRUST WASHER

18

20Y-27-22151

GEAR

19

20Y-27-22160

CARRIER

20

20Y-27-22120

GEAR

21

20Y-27-22210

BEARING

22

20Y-27-21240

THRUST WASHER

23

20Y-27-21220

PIN

24

20Y-27-21280

PIN

25

20Y-27-42510

SHAFT

26

20Y-27-21310

THRUST WASHER

27

20Y-27-42530

COVER

28

04260-01587

BALL

29

20Y-27-13281

BOLT

30

01643-31645

WASHER

31

07049-01012

PLUG

32

07044-12412

PLUG

33

07002-12434

O-RING

34

20Y-27-11582

SPROCKET

35

20Y-27-11561

BOLT

36

01010-B1660

BOLT

37

01643-31645

WASHER

38

20Y-30-21191

COVER

39

01010-81230

BOLT

40

01643-31232

WASHER

41

708-8F-00250

MOTOR ASSEMBLY
