Запчасти Komatsu PC210LC-8K ОСНОВН. КОНСТРУКЦИЯ (OPERATORґS КАБИНА) (АКСЕССУАРЫ) (/) K OPERATORґS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|1

20Y-53-00481

CAB ASSEMBLY (ROPS)

|1

20Y-53-00480

CAB ASSEMBLY

|1

20Y-53-00083

CAB ASSEMBLY

|1

20Y-53-00082

CAB ASSEMBLY

|1

20Y-53-00081

CAB ASSEMBLY

1

20Y-53-13712

COVER

2

09416-10200

BUTTON

|3

20Y-53-13722

COVER ASSEMBLY

3

20Y-53-13732

COVER

4

20Y-53-13781

RAIL

|4

20Y-54-53281

PLATE

|4

20Y-54-53341

PLATE

5

01023-10410

SCREW

6

20Y-53-13751

TRIM

7

20Y-53-13763

PLATE

8

01224-70408

SCREW

9

20Y-53-18240

COVER

10

09416-10200

BUTTON

11

20Y-53-12431

COVER

12

208-53-13270

RIVET

13

01435-00612

BOLT

14

20Y-53-12710

SEAL

15

20Y-53-12441

COVER

16

09416-10200

BUTTON

17

01435-00612

BOLT

18

20Y-53-12710

SEAL

19

20Y-53-12552

SEAL

20

20Y-53-12463

COVER

21

20Y-53-12310

COLLAR

22

01245-00616

SCREW

23

01643-70623

WASHER

24

01435-00612

BOLT

25

22B-54-17380

HAMMER

26

20Y-53-12472

COVER

27

20Y-53-12310

COLLAR

28

01245-00616

SCREW

29

01643-70623

WASHER

30

01435-00612

BOLT

31

20Y-53-18230

BRACKET

32

01435-40610

BOLT

33

20Y-53-18251

COVER

34

01245-00612

SCREW

35

01643-70623

WASHER

36

20Y-53-18320

COVER

37

205-54-51250

HANGER

38

01370-30416

SCREW

39

208-53-12991

HOLDER

40

208-53-12980

PLATE

41

01023-20616

SCREW

42

20Y-53-11752

COVER

43

01435-40610

BOLT

44

20Y-53-11761

LOCK ASSEMBLY

|44

20Y-53-11762

LOCK ASSEMBLY

45

205-54-76280

ROTOR ASSEMBLY
