Запчасти Komatsu PC210LC-8 WASTE SPEC КРЫШКА(КАБИНА ВЕРХН.) (-НАВЕСН. ОБОРУД) TABLE OF CONTENS PCLC-8 WASTE СПЕЦ-Я

|1

20Y-54-KB550

COVER ASSEMBLY

1

20Y-54-K3033

COVER

|1

20Y-54-K3030

COVER

2

20Y-00-42140

PLATE

3

01010-81230

BOLT

4

175-54-34170

WASHER

5

01010-81230

BOLT

6

01643-31232

WASHER

7

20Y-54-19930

COLLAR

8

20Y-54-19920

PLATE

9

20Y-54-75240

COVER

10

207-00-76250

PLATE

11

208-00-76240

PLATE

12

20Y-54-73730

SHEET

13

20Y-54-KC121

COVER

|13

20Y-54-78723

COVER

|13

20Y-54-KC120

COVER

|13

20Y-5478722

COVER

|13

207-00-76250

PLATE

|13

207-00-76140

PLATE

14

20Y-54-25852

LOCK

|14

20Y-54-25851

LOCK

|14

04050-13020

PIN, COTTER

|14

130-955-1960

PIN

|14

20Y-54-27561

SPRING

15

20Y-54-73190

LOCK ASSEMBLY

|15

20Y-54-27540

LOCK ASSEMBLY

16

20Y-54-75900

LOCK ASSY

|16

20Y-54-75910

PLATE

|16

20Y-54-27511

PLATE

17

20Y-54-75930

BRACKET

|17

20Y-54-27523

BRACKET

18

20Y-54-75920

LEVER

|18

21K-54-26341

LEVER

19

21K-54-26351

SPRING

20

20X-54-21460

SPRING

21

04205-11038

PIN

22

04050-13020

PIN,COTTER

23

01010-81025

BOLT

24

01643-31032

WASHER

25

20Y-54-27182

BRACKET

26

01010-81025

BOLT

27

01643-31032

WASHER

28

205-54-68440

PLATE

29

01224-40616

SCREW

30

01010-81230

BOLT

31

01643-31232

WASHER

32

01010-81230

BOLT

33

175-54-34170

WASHER

34

01010-81230

BOLT

35

01643-31232

WASHER

36

20Y-54-78171

FRAME

37

01010-81230

BOLT

38

01643-31232

WASHER
